Laser Diodes
Sanyo and Sony — 635 nm to 830 nm, 5mW to 150mW
Laser diodes continue to find new product applications as the lasing wavelength is pushed lower into the visible
spectrum. The latest generation of Visible Laser Diodes (VLD’s) operate at or near 635nm; this wavelength being
equivalent to a helium neon gas laser, is highly visible to the human eye. VLD’s in the range from 635nm to 685nm are
replacing the traditional HeNe laser in many commercial products for good reasons: lower cost, compact size, and
superior long-term reliability. Another intrinsic benefit, laser diodes are generally better suited for battery operated
devices and other low voltage applications. Please refer to the Optima website for additional information, specifications
and current pricing — http://www.optima-optics.com
Sanyo visible and Near-Infrared Laser Diode Specifications:
WAVE
PART NUMBER
PRICE
LENGTH
(nm)
* MAX
LASER
POWER
(mW)
MODE
THRESHOLD
CURRENT
TYP (mA)
OPERATING
CURRENT
TYP (mA)
PARALLEL
DIVERGENCE
FWHM (deg)
PERPENDICULAR
DIVERGENCE
FWHM (deg)
PIN
REF
BASE
DIMENSION
(mm)
DL 3148-037
DL 4038-031
DL 4038-025
DL 3147-041
DL 3147-060
DL 3149-057
DL 7140-201S
DL 8032-001
$25.30
$75.20
$292.00
$17.40
$16.80
$15.10
$47.30
$376.00
635
635
635
645
650
670
785
830
7
10
20
5
7
7
80
150
S
S
S
S
S
S
S
S
20
35
45
45
20
25
30
40
30
55
80
60
30
40
100
185
8
8
7
7.5
8
8
8
7
30
30
25
30
30
30
17
18
C
C
C
C
C
C
D
C
Ø5.6
Ø9.0
Ø9.0
Ø5.6
Ø5.6
Ø5.6
Ø5.6
Ø9.0
*MAX LASER POWER (mW) = Absolute Maximum Rating as listed on the laser diode data sheet.
All of the diodes listed above are Single Mode.
Sony Visible Laser Diode Specifications:
WAVE
PART NUMBER
PRICE
LENGTH
(nm)
MAX
LASER
POWER
(mW)
MODE
THRESHOLD
CURRENT
TYP (mA)
OPERATING
CURRENT
TYP (mA)
PARALLEL
DIVERGENCE
FWHM (deg)
PERPENDICULAR
DIVERGENCE
FWHM (deg)
PIN
REF
BASE
DIMENSION
(mm)
SLD 1132 VS
SLD 1134 VL
$30.10
$17.00
635
655
5
5
S
S
50
65
60
75
7
8.5
32
35
A
F
Ø5.6
Ø5.6
Schematic Diagram of Laser Diode / Photodiode Internal Circuit Connections:
3
3
2
2
LD
PD
LD
PD
LD
PD
LD
PD
1
2
1
2
1
3
1
3
Pin reference diagram A
Pin reference diagram F
Pin reference diagram C
Pin reference diagram D
Optima Precision Inc.
Phone: (503) 638-2525
email: sales1@optima-optics.com
url: http://www.optima-optics.com
Revised 01Jan09
