P10TG-xxxxE/Z2:1(H35)LF
PM6-SERIES
Rev.09-2009
2 Watt
2:1
Wide Input
Regulated
DIP24 Plastic
Case
1.5 or 3.5 KV
DC I/O Isolation
SINGLE
and
DUAL
Output
Continuous Short Circuit Prot.
Input Specifications
Voltage Range
Input Filter
Input Reflected Ripple Current¹
Output Specifications
Voltage Accuracy
Short Circuit Protection
Line Regulation
Load Regulation
Ripple and Noise
(20Mhz bandwidth)
Temperature Coefficient
General Specifications
Efficiency
I/O Isolation Voltage
(3 sec.)
I/O Isolation Capacity
I/O Isolation Resistance
Switching Frequency
(typical)
Humidity
Reliability Calculated MTBF
(MIL-HDBK-217F)
Physical Specifications
Case Material
Potting Material
Weight
Environment Specifications
Operating Temperature
Maximum Case Temperature
Storage Temperature
Cooling
RoHS Conform
Mainzer Straße 151–153
D-55299 Nackenheim
Tel. +49 6135 7026-0
Fax: +49 6135 931070
www.peak-electronics.de
peak@peak-electronics.de
The PM6 series P10TG-xxxxE/Z2:1(H30)LF is a family of cost effective 2W
single & dual output DC-DC converters with a wide input Voltage of 2:1.
These converters are encapsulated in an ultra miniature DIP24 plastic or
metal case. High performance features: 1500VDC up to 3500VDC
input/output isolation, high efficiency operation, output voltage accuracy of
±1% maximum, wide input range 2:1 and low output ripple and noise.
All specifications typical at Ta=25° nominal input voltage and full load unless otherwise specified
C,
2:1 Wide Input
Pi Type
35 mA pk-pk
± 1%
Indefinite
(automatic recovery)
± 0.5%
± 0.5% / ± 1.5%
(only 3.3 / ±3.3 Vout Models)
60 mV pk-pk
± 0.02% / °
C
See Table
1500 VDC
(3500 VDC optional)*
470 pF, typ.
1000 MOhm
266 kHz, typ.
95% rel H
> 1.121 Mhrs
Non Conductive Black Plastic
Epoxy
(UL94V-0 rated)
~ 13.5g, typ.
-40 to +85°
(ambient)
C
100°
C
-40 to +125°
C
Free Air Convection
Soldering 260° max.
(1.5mm from case 10s.)
C,
PM6-Series – P10TG-xxxxE/Z2:1(H35)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 1/3
Selection Guide
Single/Dual
Output
)
A)
)
(mA
d (m
mA) ad (mA
oa
)
o ad
d(
L
.L
Lo a
u F)²
VDC
ll Lo
DC)
Full
Min
)
ad (
ge (
t No rent Fu
e (V
ent
ent
a
n
%
r
r
g
Lo
cy (
Volt
Cur
Cur
urre
ur
olta
ito r
ut V
ut C Input C
tput
tput
tput
pac
icien
Inp
Inp
Ou
Ou
Ou
Eff
Ca
Order #
SINGLE OUTPUT
P10TG-123R3E2:1LF
P10TG-1205E2:1LF
P10TG-1209E2:1LF
P10TG-1212E2:1LF
P10TG-1215E2:1LF
P10TG-1224E2:1LF
P10TG-243R3E2:1LF
P10TG-2405E2:1LF
P10TG-2409E2:1LF
P10TG-2412E2:1LF
P10TG-2415E2:1LF
P10TG-2424E2:1LF
P10TG-483R3E2:1LF
P10TG-4805E2:1LF
P10TG-4809E2:1LF
P10TG-4812E2:1LF
P10TG-4815E2:1LF
P10TG-4824E2:1LF
DUAL OUTPUT
P10TG-123R3Z2:1LF
P10TG-1205Z2:1LF
P10TG-1209Z2:1LF
P10TG-1212Z2:1LF
P10TG-1215Z2:1LF
P10TG-1224Z2:1LF
P10TG-243R3Z2:1LF
P10TG-2405Z2:1LF
P10TG-2409Z2:1LF
P10TG-2412Z2:1LF
P10TG-2415Z2:1LF
P10TG-2424Z2:1LF
P10TG-483R3Z2:1LF
P10TG-4805Z2:1LF
P10TG-4809Z2:1LF
P10TG-4812Z2:1LF
P10TG-4815Z2:1LF
P10TG-4824Z2:1LF
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
30
30
30
30
30
30
20
20
20
20
20
20
12
12
12
12
12
12
223
222
219
219
219
219
109
107
107
107
107
107
56
56
56
56
56
56
3.3
5
9
12
15
24
3.3
5
9
12
15
24
3.3
5
9
12
15
24
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
600
400
222
167
133
83
600
400
222
167
133
83
600
400
222
167
133
83
74
75
76
76
76
76
76
78
78
78
78
78
74
75
75
75
75
75
680
680
330
220
100
33
680
680
330
220
100
33
680
680
330
220
100
33
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
30
30
30
30
30
30
20
20
20
20
20
20
12
12
12
12
12
12
229
219
219
219
219
219
112
109
107
107
107
107
56
56
56
56
56
56
± 3.3
±5
±9
± 12
± 15
± 24
± 3.3
±5
±9
± 12
± 15
± 24
± 3.3
±5
±9
± 12
± 15
± 24
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
± 300
± 200
± 111
± 83
± 67
± 42
± 300
± 200
± 111
± 83
± 67
± 42
± 300
± 200
± 111
± 83
± 67
± 42
72
75
76
76
76
76
74
76
78
78
78
78
74
75
75
75
75
75
± 330
± 330
± 100
± 47
± 33
± 22
± 330
± 330
± 100
± 47
± 33
± 22
± 330
± 330
± 100
± 47
± 33
± 22
If you need other specifications, please enquire.
* For optional 3.5kV DC I/O Isolation, please add “H35” before LF!
Example: P10TG-1205Z2:1H35LF for 3.5kV
PM6-Series – P10TG-xxxxE/Z2:1(H35)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 2/3
Package / Pinning / Derating
20.32
(0.80)
15.24
(0.60)
App Notes:
¹ =
Measured Input reflected ripple current with a simulated source inductance of 12uH.
² =
Tested by nominal Vin and constant resistive load.
PM6-Series – P10TG-xxxxE/Z2:1(H35)LF – Single and Dual Output – DIP24 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 3/3
0.25
(0.01)
PIN CONNECTIONS
#
SINGLE DUAL SINGLE
3.5KV
DUAL
3.5KV
1
+Vin
+Vin
Omitted
Omitted
2
N.C.
- Vout
- Vin
- Vin
3
N.C.
Common - Vin
- Vin
9
Omitted Omitted Omitted
Common
10
- Vout Common Omitted
Omitted
11
+Vout +Vout
N.C.
- Vout
12
- Vin
- Vin
Omitted
Omitted
13
- Vin
- Vin
Omitted
Omitted
14
+Vout +Vout
+Vout
+Vout
15
- Vout Common Omitted
Omitted
16
Omitted Omitted - Vout
Common
22
N.C.
Common +Vin
+Vin
23
N.C.
- Vout
+Vin
+Vin
24
+Vin
+Vin
Omitted
Omitted
others
Omitted
