LDF4.5P-50-40: DescriptionRF N Connector, Cable Mount; CategoryThe connector The connector; File Size55KB，1 Pages; ManufacturerCommScope Inc

Download Datasheet Parametric Compare View All

LDF4.5P-50-40 Overview

RF N Connector, Cable Mount

LDF4.5P-50-40 Parametric

Parameter Name	Attribute value
Maker	CommScope Inc
Reach Compliance Code	unknown
Connector type	RF N CONNECTOR
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	LDF4.5P-50-40
Installation type	CABLE
Maximum operating frequency	0.96 GHz
Options	GENERAL PURPOSE
Panel mounting	NO

Preview

Download Datasheet

View All

N Male

L4.5PNM-RC

N Female

L4.5PNF-RC

7-16 DIN Male

L4.5PDM-RC

7-16 DIN Female

L4.5PDF-RC

Connectors

Interface

N Male

N Female

7-16 DIN Male

7-16 DIN Female

Description

Ring Flare

Type

Number

L4.5PNM-RC

L4.5PNF-RC

L4.5PDM-RC

L4.5PDF-RC

Inner Contact

Attachment

Captivated

Outer Contact

Attachment

Self Flare

Plating

Code

Max. Length

in (mm)

3.2 (81.5)

3.0 (76)

3.1 (78)

3.25 (82)

Max. Dia.

in (mm)

1.42 (36)

1.32 (33.5)

1.17 (29.8)

Plating Codes:

SG - Silver Plated Body and Gold Plated Pin, SS - Silver Plated Body and Pin

Connector Accessories

– See page 624.

Factory Attached Connectors

– For factory made cable

assemblies and jumper cables, see pages 584-587.

Standard VSWR Specifications

Frequency

Band, GHz

0.806-0.960

and 1.7-2.0

1-25 ft

(0.3-8 m)

1.12 (24.9)*

Assembly VSWR, Maximum (R.L., dB)

25-100 ft

100-200 ft

200-500 ft

(8-30 m)

(30-60 m)

(60-150 m)

1.13 (24.3)*

Above 500 ft

(150 m)

1.13 (24.3)**

Type Number

LDF4.5-50

LDF4.5RN-50

* Expected typical values based on guaranteed 1.13 VSWR for bulk cable and Type N or DIN straight connectors. If guaranteed values are required, contact Andrew.

** 1.13 VSWR guaranteed for bulk standard cable lengths 500 ft and above.

Low VSWR Specifications, Type LDF4.5P-50-( )

Frequency

Band, GHz

0.806-0.960

1.7-2.2

0.806-0.960

and 1.7-2.2

Type Number

LDF4.5P-50-40

LDF4.5P-50-41

LDF4.5P-50-42

Using Connector Type*

7-16 DIN

1-25 ft

(0.3-8 m)

1.08 (28.3)

1.10 (26.4)

Assembly VSWR, Maximum (R.L., dB)

25-100 ft

100-200 ft

200-500 ft

(8-30 m)

(30-60 m)

(60-150 m)

1.08 (28.3)

1.10 (26.4)

1.09 (27.3)

1.10 (26.4)

Above 500 ft

(150 m)

1.10 (26.4)

* Connectors ordered separately

VSWR values apply to straight connectors only, are guaranteed for factory fit assemblies, and are typical for field cut lengths. If two different connector interfaces are

selected, the higher VSWR value is guaranteed.

•

U.K. 0800-250055

•

Australia 1800-803 219

•

New Zealand 0800-441-747

Revised 3/01

Visit us at:

www.andrew.com

501

LDF4.5P-50-40 Related Products

	LDF4.5P-50-40	L4.5PNF-RC	L4.5PNM-RC	LDF4.5P-50-41	LDF4.5P-50-42
Description	RF N Connector, Cable Mount	RF N Connector, Female, Cable Mount	RF N Connector, Male, Cable Mount	RF Connector, Cable Mount	RF Connector, Cable Mount
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
Connector type	RF N CONNECTOR	RF N CONNECTOR	RF N CONNECTOR	RF CONNECTOR	RF CONNECTOR
DIN compliance	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Panel mounting	NO	NO	NO	NO	NO
Maker	CommScope Inc	-	-	CommScope Inc	CommScope Inc
Coupling type	THREADED	THREADED	THREADED	-	-
Manufacturer's serial number	LDF4.5P-50-40	-	-	LDF4.5	LDF4.5
