F-217
SHF–110–01–L–D–RA
ESHF–125–01–L–D–SM–LC
EHF–108–01–F–D–SM–LC
ESHF–105–01–L–D–SM
(1,27 mm) .050"
(1.27
EHF–125–01–L–D–SM–LC
SHF, ESHF, EHF, ECF SERIES
SHROUDED & EJECTOR IDC HEADER
SHF, ESHF Mates with:
FFSD, FFTP (SHF)
EHF Mates with:
FFSD*, FFTP
TYPE
STRIP
1
NO. PINS
PER ROW
01
PLATING
OPTION
D
TAIL
STYLE
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?SHF,
www.samtec.com?ESHF or
www.samtec.com?EHF
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +125 °C
RoHS Compliant:
Yes
= Mates with
FFSD without
Strain Relief
SHF
04, 05, 06, 08,
10, 11, 12, 13,
15, 17, 20, 25
(Standard sizes)
A
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
TYPE
STRIP
A
No. of pins x
(6.35) .250
–L
= Through-
hole
–TH
–RA
= Mates with
FFSD with
Strain Relief
ESHF
= Right-
angle
(1.27)
.050 TYP
02 04
SHF
(1.27) .050 +
ESHF
(1.27) .050 +
No. of pins x
(10.16) .400
= Surface
Mount
–SM
= Locking
Clip
(Not available
with –RA)
(Manual
placement
required)
–LC
= Tape &
Reel
Packaging
(1.89)
.075
–TR
–K
01 03
–TH
(5.33)
.210
(1.91)
.075
(0.41) .016 SQ
–RA
–SM
(5.46)
.215
(5.85) .230
–SM
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
(1.27)
.050
= (6.50 mm)
.256" DIA
Polyimide
Film Pick &
Place Pad
(–SM only)
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
–TH
–RA
(1.27)
.050
EHF
1
NO. PINS
PER ROW
01
PLATING
OPTION
D
TAIL
OPTION
Leave blank
for Through-
Hole version
OTHER
OPTION
ALSO AVAILABLE
(MOQ Required)
• Other sizes
Contact Samtec.
04, 05, 08, 10,
13, 17, 20, 25
(Standard sizes)
(Locks FFSD cable to EHF header)
(8.76)
.345
EJECTOR HEADER CAP
= Gold flash on post,
Matte Tin on tail
–F
–L
= Surface
Mount
–SM
= Polarized Position
(–RA not available)
–“XX”
–LC
No. of positions x (1.27) .050 + (14.48) .570
02
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= Right-angle
–RA
= Locking Clip
(–SM only)
(Manual placement
required)
(9.65)
.380
No. of positions x (1.27) .050
+ (18.03) .710
ECF
NO. PINS PER ROW
05, 08, 10,
13, 17, 20, 25
(1.27)
.050
01
(3.05)
.120
(8.51)
.335
= (7.50 mm) .295" DIA
Polyimide Film Pick
& Place Pad
–K
–P
–SM
–RA
–TH
(7.52) .296
–SM
(0.41)
.016 SQ
(1.52)
.060
*Important Note:
EHF will not mate to FFSD
with strain relief (-SR option),
see ESHF series.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(11.30)
.445
(8.26)
.325
= Pick & Place Pad
(–SM only)
(6.67)
(2.29)
.263
.090
(2.72)
.107
(1.27)
.050
= Tape & Reel
Packaging
(–LC not available)
(1.27) .050
–RA
–TR
–LC
–TH
