SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 378, REV. -
SHD116044
SHD116044A
SHD116044B
HERMETIC POWER SCHOTTKY RECTIFIER
200C Maximum Operation Temperature
DESCRIPTION:
100 VOLT, 3 AMP, HERMETIC POWER SCHOTTKY RECTIFIER IN A SHD-1/1A/1B
PACKAGE.
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
MAXIMUM DC OUTPUT CURRENT (With Cathode Maintained @ T
C
=100 C)
MAXIMUM NONREPETITIVE FORWARD SURGE CURRENT
(t=8.3ms, Sine)
MAXIMUM JUNCTION CAPACITANCE
(V
r
=5V)
C
T
Rq
JC
Top/Tstg
100
3.7
-65 to
+ 200
pF
C/W
C
O
ALL RATINGS ARE @ T
C
= 25 C UNLESS OTHERWISE SPECIFIED.
¡
SYMBOL
PIV
I
O
I
FSM
MAX.
100
3.0
55
UNITS
Volts
Amps
Amps
MAXIMUM THERMAL RESISTANCE (Junction to Mounting Surface, Cathode)
MAXIMUM OPERATING AND STORAGE TEMPERATURE RANGE
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP, Pulsed (I
f
= 3.0 Amps)
T
J
= 125
C
MAXIMUM REVERSE CURRENT (I
r
@ 100V PIV)
T
J
= 25
C
T
J
= 25
C
V
f
0.84
0.68
0.07
1.6
mA
Volts
T
J
= 125
C
I
r
221 WEST INDUSTRY COURT DEER PARK, NY 11729-4681 PHONE (631) 586-7600 FAX (631) 242-9798
World Wide Web - http://www.sensitron.com E-mail Address - sales@sensitron.com
SENSITRON
DATA SHEET 378, REV. -
MECHANICAL DIMENSIONS: In Inches / mm
.225±.010
(5.71±.254)
SHD116044
SHD116044A
SHD116044B
.375±.020
(9.52±.508)
.225±.010
(5.71±.254)
.225±.010
(5.71±.254)
.375±.020
(9.52±.508)
.150±.010
(3.81±.254)
.225±.010
(5.71±.254)
.225±.010
(5.71±.254)
.125±.010
(3.17±.254)
.225±.010
(5.71±.254)
.015±.005
(.381±.127)
.075 (1.91) Max
.075 (1.91) M ax
A lum ina R ing
M oly B ase
M oly Lid
Copper Anode
Moly Lid
.020±.005 R
(.508±.127 )
Alumina Ring
.090 (2.29) Max
.020±.005 R
(.508±.127 )
Alumina Ring
Moly Base
(Cathode)
Moly Anode
.020±.002
(.508±.051)
.060±.010
(1.52±.254)
Moly Base
(Cathode)
.015±.002
(.381±.051)
.060±.010
(1.52±.254)
SHD-1
SHD-1A
SHD-1B
Typical Forward Characteristics
10
1
Instantaneous Reverse Current - I
R
(mA)
Typical Reverse Characteristics
10
0
200°
C
175 °
C
150 °
C
125 °
C
200 °
C
10
0
Instantaneous Forward Current - I
F
(A)
10
-1
10
-2
100 °
C
75 °
C
50 °
C
175 °
C
10
-3
10
-1
125 °
C
10
-4
25 °
C
10
-5
0
20
40
60
80
Reverse Voltage - V
R
(V)
100
120
Junction Capacitance - C
T
(pF)
25 °
C
10
-2
Typical Junction Capacitance
90
80
70
60
50
40
30
20
10
0
20
40
60
80
Reverse Voltage - V
R
(V)
100
120
10
-3
0.1
0.2
0.3
0.4
0.5
0.6
0.7
Forward Voltage Drop - V
F
(V)
0.8
