DG526AK/883B: Description16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28; CategoryAnalog mixed-signal IC The signal circuit; File Size308KB，16 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

DG526AK/883B Overview

16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28

DG526AK/883B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	CERDIP-28
Contacts	28
Reach Compliance Code	not_compliant
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-GDIP-T28
JESD-609 code	e0
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	16
Number of functions	1
Number of terminals	28
Nominal off-state isolation	55 dB
On-state resistance matching specifications	16.2 Ω
Maximum on-state resistance (Ron)	400 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Encapsulate equivalent code	DIP28,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	+-15 V
Certification status	Not Qualified
Filter level	MIL-STD-883 Class B
Maximum seat height	5.92 mm
Maximum signal current	0.02 A
Maximum supply current (Isup)	4.5 mA
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	1000 ns
Maximum connection time	1500 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	15.24 mm

Preview

Download Datasheet

View All

Semiconductor

April 1999

UCT

DUC

ROD TE PRO 747

TE P

OLE UBSTITU 00-442-7

OBS LE S

1-8

SIB lications arris.co

A PO

FOR Central A centapp

call r email:

DG526, DG527,

DG528, DG529

Analog CMOS

Latchable Multiplexers

Features

• Direct RESET

• TTL and CMOS Compatible Address and Enable

Inputs

• Maximum Power Supply Rating . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switching

• Alternate Source

Description

The DG526, DG527, DG528, and DG529 are CMOS

Monolithic 16-Channel/Dual 4-Channel Analog Multiplexers.

Each device has on-chip address and control latches to sim-

plify design in microprocessor based applications. The DG526

uses 4 address lines to control its 16 channels; the DG527,

DG528 both use 3 address lines to control their 8 channels;

and the DG529 uses 2 address lines to control its 4 channels.

The enable pin is used to enable the address latches during

the WR pulse. It can be hard wired to the logic supply if one of

the channels will always be used (except during a reset) or it

can be tied to address decoding circuitry for memory mapped

operation. The RS pin is used to clear all latches regardless of

the state of any other latch or control line. The WR pin is used

to transfer the state of the address control lines to their

latches, except during a reset or when EN is low.

A channel in the ON state conducts signals equally well in

both directions. In the OFF state each channel blocks volt-

ages up to the supply rails. The address inputs, WR, RS and

the enable input are TTL and CMOS compatible over the full

speciﬁed operation temperature range.

Applications

• Data Acquisition Systems

• Communication Systems

• Automatic Test Equipment

• Microprocessor Controlled Systemd

Part Number Information

PART

NUMBER

DG526AK

DG526AK/883B

DG526BK

DG526BY

DG526CJ

DG526CK

DG526CY

DG527AK

DG527AK/883B

DG527BK

DG527BY

DG527CJ

DG527CK

DG527CY

TEMP.

RANGE (

-55 to 125

-25 to 85

0 to 70

-55 to 125

-25 to 85

0 to 70

PACKAGE

28 Ld CERDIP

28 Ld SOIC

28 Ld PDIP

28 Ld CERDIP

28 Ld SOIC

28 Ld CERDIP

28 Ld SOIC

28 Ld PDIP

28 Ld CERDIP

28 Ld SOIC

PKG. NO.

F28.6

M28.3

E28.6

F28.6

M28.3

F28.6

M28.3

E28.6

F28.6

M28.3

PART

NUMBER

DG528AK

DG528AK/883B

DG528BK

DG528BY

DG528CJ

DG528CK

DG528CY

DG529AK

DG529AK/883B

DG529BK

DG529BY

DG529CJ

DG529CK

DG529CY

TEMP.

RANGE (

-55 to 125

-25 to 85

0 to 70

-55 to 125

-25 to 85

0 to 70

PACKAGE

18 Ld CERDIP

18 Ld SOIC

18 Ld PDIP

18 Ld CERDIP

18 Ld SOIC

18 Ld CERDIP

18 Ld SOIC

18 Ld PDIP

18 Ld CERDIP

18 Ld SOIC

PKG. NO.

F18.3

M18.3

E18.3

F18.3

M18.3

F18.3

M18.3

E18.3

F18.3

M18.3

CAUTION: These devices are sensitive to electrostatic discharge. Users should follow proper IC Handling Procedures.

Harris Corporation 1999

File Number

3139.2

12-1
