2SA1690 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> 2SA1690

2SA1690: DescriptionTransistor,; CategoryDiscrete semiconductor The transistor; File Size62KB，1 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

2SA1690 Overview

Transistor,

2SA1690 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	compli
Maximum collector current (IC)	0.2 A
Configuration	Single
Minimum DC current gain (hFE)	56
Polarity/channel type	PNP
Maximum power dissipation(Abs)	2 W
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

2SA1690 Related Products

	2SA1690	2SD2126	RXT-A76	RXT2222A	RXT-A28	BCX56	RXT3904	RXT3906
Description	Transistor,	Transistor,	Small Signal Bipolar Transistor, 0.5A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon	Small Signal Bipolar Transistor, 0.6A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon,	Small Signal Bipolar Transistor, 0.5A I(C), 80V V(BR)CEO, 1-Element, NPN, Silicon,	Small Signal Bipolar Transistor, 1A I(C), 80V V(BR)CEO, 1-Element, NPN, Silicon	Small Signal Bipolar Transistor, 0.2A I(C), 40V V(BR)CEO, 1-Element, NPN, Silicon	Small Signal Bipolar Transistor, 0.2A I(C), 40V V(BR)CEO, 1-Element, PNP, Silicon
Is it Rohs certified?	conform to	incompatible	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	,	,	SMALL OUTLINE, R-PSSO-F3	SMALL OUTLINE, R-PSSO-F3	SMALL OUTLINE, R-PSSO-F3	SMALL OUTLINE, R-PDSO-G3	SMALL OUTLINE, R-PSSO-F3	SMALL OUTLINE, R-PSSO-F3
Reach Compliance Code	compli	compli	unknown	compliant	compliant	unknown	unknown	unknown
Maximum collector current (IC)	0.2 A	2 A	0.5 A	0.6 A	0.5 A	1 A	0.2 A	0.2 A
Configuration	Single	Single	DARLINGTON	SINGLE	DARLINGTON	SINGLE	SINGLE	SINGLE
Minimum DC current gain (hFE)	56	82	20000	100	10000	40	100	100
Polarity/channel type	PNP	NPN	PNP	NPN	NPN	NPN	NPN	PNP
Maximum power dissipation(Abs)	2 W	2 W	1 W	1 W	0.5 W	2 W	1 W	1 W
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
Base Number Matches	1	1	1	1	1	-	-	-
ECCN code	-	-	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Shell connection	-	-	COLLECTOR	COLLECTOR	COLLECTOR	COLLECTOR	COLLECTOR	COLLECTOR
Collector-emitter maximum voltage	-	-	50 V	40 V	80 V	80 V	40 V	40 V
JESD-30 code	-	-	R-PSSO-F3	R-PSSO-F3	R-PSSO-F3	R-PDSO-G3	R-PSSO-F3	R-PSSO-F3
Number of components	-	-	1	1	1	1	1	1
Number of terminals	-	-	3	3	3	3	3	3
Package body material	-	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	-	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	-	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	-	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Terminal form	-	-	FLAT	FLAT	FLAT	GULL WING	FLAT	FLAT
Terminal location	-	-	SINGLE	SINGLE	SINGLE	DUAL	SINGLE	SINGLE
Maximum time at peak reflow temperature	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
transistor applications	-	-	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	-	-	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	-	-	125 MHz	300 MHz	125 MHz	100 MHz	300 MHz	250 MHz
