2SB1594
TOSHIBA Transistor Silicon PNP Epitaxial Type (Darlington Power Transistor)
2SB1594
Power Amplifier Applications
Unit: mm
•
•
High breakdown voltage: V
CEO
=
−160
V (min)
Complementary to 2SD2449
Maximum Ratings
(Tc = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
(Tc = 25°C)
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
−160
−160
−5
−10
−1
150
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
―
―
2-21F1A
Equivalent Circuit
COLLECTOR
TOSHIBA
Weight: 9.75 g (typ.)
BASE
≈
10
Ω
EMITTER
Electrical Characteristics
(Tc = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
DC current gain (1)
DC current gain (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
(Note)
h
FE (2)
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
=
−160
V, I
E
= 0
V
EB
=
−5
V, I
C
= 0
I
C
=
−50
mA, I
B
= 0
V
CE
=
−5
V, I
C
=
−8
A
V
CE
=
−5
V, I
C
=
−12
A
I
C
=
−8
A, I
B
=
−8
mA
V
CE
=
−5
V, I
C
=
−8
A
V
CE
=
−5
V, I
C
=
−1
A
V
CB
=
−10
V, I
E
= 0, f = 1 MHz
Min
―
―
−160
3000
2000
―
―
―
―
Typ.
―
―
―
―
―
―
―
30
150
Max
−5
−5
―
20000
―
−3.0
−3.0
―
―
V
V
MHz
pF
Unit
µA
µA
V
Note: h
FE (1)
classification
A: 3000 to 10000, B: 5000 to 15000, C: 7000 to 20000
1
2004-07-07
