JZ-604-YCY TC TRAY CABLE
PVC power cable, screened, open installation TC-ER, NFPA 79,
90°C, 600 V, EMC-preferred type, meter marking
Technical data
•
PVC power cable, screened to
UL Std.1277 TRAY CABLE
• Multinorm
also conforms to the following standards:
AWM-Style 2587 to UL Std.758 and
CSA C22.2 No 210 I/II A/B 90°C 600 V
• Temperature range
dry environment
flexing -5°C to +90°C
fixed installation -25°C to +90°C
wet environment
flexing -5°C to +75°C
fixed installation -25°C to +75°C
• Nominal voltage
UL 600 V
• Test voltage
3000 V
• Breakdown voltage
min. 6000 V
• Minimum bending radius
10x cable Ø
• Radiation resistance
up to 80x10
6
cJ/kg (up to 80 Mrad)
• Coupling resistance
max. 250 Ohm/km
Cable structure
•
Bare copper, fine wire conductors, acc. to
DIN VDE 0295 cl.5, BS 6360 cl.5 and
IEC 60228 cl.5
•
Core insulation of special PVC class 12 B
to tab.50.155 acc. to UL Std.1581
type THHW acc. to UL Std.83
•
Core identification to DIN VDE 0293
black cores with continuous white
numbering
•
GN-YE conductor, 3 cores and above
in the outer layer
•
Cores stranded in layers with
optimal lay length
•
PVC-inner sheath acc. to UL Std.1277
tab.11.2
•
Tinned copper braided screening,
approx. 85% coverage
•
Outer sheath of special PVC
acc. to UL Std.1277 tab.11.2,
•
Sheath colour: black (RAL 9005)
•
With meter marking
Properties
•
The materials used during manufacturing
are cadmium-free, contain no silicone
and are free from substances harmful
to the wetting properties of lacquers
•
UV resistant
Tests
•
Self-extinguishing and flame retardant
acc. to CSA FT4
•
UL OIL RES I
•
Class 1 Div. 2 per
NEC Art. 336, 392, 501
Note
•
G = with GN-YE conductor
x = without GN-YE conductor (OZ)
•
AWG sizes are approximate equivalent
values. The actual cross section is in mm².
•
Unscreened analogue type:
JZ 604 TC TRAY CABLE
Application
USA NFPA 79 conformant flexible power cables up to 600 V, for all machinery in tool and plant constuction, suitable for installation in dry, humid and
damp environments, in the open and in pipes. For underground installation and for open, unprotected installation from the cable rack to machines
and industrial plants.
EMC
= Electromagnetic compatibility
To optimize the EMC features we recommend a large round contact of the copper braiding on both ends.
= Product conforms with Low-Voltage Directive 2014/35/EU.
Part no.
No.cores x
cross-sec.
mm²
3 G 16
4 G 16
5 G 16
7 G 16
3 G 25
4 G 25
5 G 25
7 G 25
3 G 35
4 G 35
5 G 35
3 G 50
AWG-No. Outer Ø Cop.
app. mm weight
kg / km
6
25,2
653,0
6
27,8
807,0
6
31,2
940,0
6
34,5
1345,0
4
29,0
920,0
4
32,4
1169,0
4
36,4
1420,0
4
40,3
1921,0
2
32,4
1250,0
2
36,2
1680,0
2
40,5
2020,0
1
40,4
1887,0
Weight
app.
kg / km
1060,0
1572,0
2002,0
2604,0
1955,0
2218,0
2757,0
3523,0
2289,0
2926,0
3545,0
3379,0
Part no.
No.cores x
cross-sec.
mm²
4 G 50
5 G 50
3 G 70
4 G 70
5 G 70
3 G 95
4 G 95
5 G 95
3 G 120
4 G 120
5 G 120
AWG-No. Outer Ø Cop.
app. mm weight
kg / km
1
45,5
2370,0
1
50,0
2880,0
2/0
46,7
2516,0
2/0
51,1
3257,0
2/0
56,0
4032,0
3/0
50,1
3086,0
3/0
55,0
4060,0
3/0
60,5
5244,0
4/0
54,0
4176,0
4/0
59,5
5231,0
4/0
64,5
6624,0
Weight
app.
kg / km
4439,0
5312,0
4557,0
5632,0
6681,0
5612,0
6820,0
8172,0
6711,0
8256,0
10233,0
27.09.2016 / Dimensions and specifications may be changed without prior notice.
69804
69805
69806
69807
69808
69809
69810
69811
69812
69813
69814
69815
69816
69817
69818
69819
69820
69821
69822
69823
69824
69825
69826
Dimensions and specifications may be changed without prior notice. (RN01)
