HMD16HO-Q: DescriptionBase Station/Broadcast Transmission Antenna, 2100MHz Min, 2300MHz Max, 14dB Gain, 360deg 3dB Beamwidth; CategoryWireless rf/communication Radio frequency and microwave; File Size45KB，1 Pages; ManufacturerCommScope Inc

Download Datasheet Parametric View All

HMD16HO-Q Overview

Base Station/Broadcast Transmission Antenna, 2100MHz Min, 2300MHz Max, 14dB Gain, 360deg 3dB Beamwidth

HMD16HO-Q Parametric

Parameter Name	Attribute value
Maker	CommScope Inc
Reach Compliance Code	unknown
Beam Width-E	0.5 deg
Beamwidth-H	360 deg
Characteristic impedance	50 Ω
Gain	14 dB
Omnidirectional	YES
Maximum operating frequency	2300 MHz
Minimum operating frequency	2100 MHz
polarization	LINEAR HORIZONTAL
RF/Microwave Device Types	BASE STATION/BROADCAST TRANSMISSION ANTENNA
Maximum transmission power	800 W
Maximum voltage standing wave ratio	1.5

Preview

Download Datasheet

View All

Standard Single P, Q, and R-Band Antennas

Type Number:

HMDxxpa-bzz

xx = Number of bays (8, 12, 16, 24, or 32)

p = Polarization (H or V)

a = Azimuth pattern type (O, C, W, or N; see page 307)

zz = Beam tilt in tenths of a degree

b = P, Q, or R

P = 1900 - 2100 MHz

Q = 2100 - 2300 MHz

R = 2300 - 2500 MHz

Input Type

Gain

Electrical Specifications

Frequency Band, MHz

Polarization

Input Power (watts)

8-Bay

12, 16, 24, or 32-Bay

Input VSWR

Beam Tilt

P, Q, R at left

Vertical or Horizontal

500**

800**

1.5:1 Maximum

0.5° Standard (8, 12, 16 Bay)

0.75° Standard (24, 32 Bay)

7/8" EIA

See Gain Data for W-band antennas for

reference. Contact Andrew for gain in a

specific band.

** Peak of sync for analog systems (NTSC, PAL, etc.)

Mechanical Data

Antenna

Type

Mount Type

Shear

lb (N)

Overturning Moment

lb-ft (N-m)

Height (H)

in (cm)

Radome Dia

in (cm)

Weight

lb (kg)

1900 - 2100 MHz (P Band)*

HMD8VO-P

HMD12VO-P

HMD16VO-P

2100 - 2300 MHz (Q Band)

HMD8HO-Q

HMD12HO-Q

HMD16HO-Q

HMD8HC-Q

HMD12HC-Q

HMD16HC-Q

HMD8VO-Q

HMD12VO-Q

HMD16VO-Q

HMD8VC-Q

HMD12VC-Q

HMD16VC-Q

2300 - 2500 MHz (R Band)

HMD8HO-R

HMD12HO-R

HMD16HO-R

HMD8VO-R

HMD12VO-R

HMD16VO-R

HMD8HW-R

HMD12HW-R

HMD16HW-R

HMD24HW-R

HMD8HN-R

HMD12HN-R

HMD16HN-R

HMD24HN-R

138 (614)

157 (699)

187 (832)

138 (614)

157 (699)

187 (832)

80 (356)

115 (212)

155 (689)

205 (912)

80 (356)

115 (212)

155 (689)

205 (912)

367 (495)

523 (711)

826 (1123)

367 (495)

523 (711)

826 (1123)

–

44 (112)

60 (152)

86 (218)

44 (112)

60 (152)

86 (218)

39 (99)

61 (155)

73 (185)

108 (274)

39 (99)

61 (155)

73 (185)

108 (274)

5 (13)

8 (20)

50 (23)

55 (25)

60 (27)

55 (25)

60 (27)

65 (30)

70 (32)

80 (36)

95 (43)

110 (50)

70 (32)

80 (36)

95 (43)

110 (50)

148 (659)

173 (770)

204 (908)

115 (512)

155 (689)

260 (1157)

175 (779)

212 (943)

260 (1157)

112 (498)

129 (573)

162 (720)

321 (436)

533 (725)

859 (1168)

–

488 (664)

768 (1044)

1224 (1665)

–

52 (132)

74 (188)

101 (257)

61 (155)

73 (185)

92 (234)

47 (119)

67 (170)

93 (236)

52 (132)

74 (188)

101 (257

5 (13)

8 (20)

5 (13)

50 (23)

55 (25)

60 (27)

50 (23)

55 (25)

70 (32)

55 (25)

60 (27)

65 (30)

45 (20)

50 (23)

55 (25)

175 (779)

212 (943)

260 (1157)

488 (664)

768 (1044)

1224 (1665)

47 (119)

67 (170)

93 (236)

8 (20)

55 (25)

65 (30)

75 (34)

* When specifying the Australian Band 2076-2111 MHz use P Band.

Notes:

1) Wind loads are based on 50/33 psf loading. 2) For Mount Type A, overturning moments are taken about the center of the mounting bracket. 3) HC parameters cover the

HW and HN patterns. 4) VC parameters cover VW and VN patterns. 5) 44.5 lb (198 N) included in shear for Type C mount. 6) Other mount types available on request.
