77DBG25POL2VFM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 77DBG25POL2VFM

77DBG25POL2VFM: DescriptionCONNECTOR,D-SHELL,PCB MNT,RECEPT,25 CONTACTS,PIN,0.109 PITCH,PC TAIL TERMINAL,M3; CategoryThe connector The connector; File Size142KB，8 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

77DBG25POL2VFM Overview

CONNECTOR,D-SHELL,PCB MNT,RECEPT,25 CONTACTS,PIN,0.109 PITCH,PC TAIL TERMINAL,M3

77DBG25POL2VFM Parametric

Parameter Name	Attribute value
Objectid	303190771
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	GND TABS & FRONT SCREWLOCK M3
body width	0.488 inch
subject depth	0.22 inch
body length	2.083 inch
Body/casing type	RECEPTACLE
Contact to complete cooperation	AU ON NI
Contact completed and terminated	GOLD OVER NICKEL
Contact point gender	MALE
Contact material	BRASS
contact mode	STAGGERED
Contact resistance	8.5 mΩ
Contact style	MACHINE SCREW
Dielectric withstand voltage	1000VAC V
maximum insertion force	3.336 N
Insulation resistance	5000000000 Ω
insulator material	GLASS FILLED POLYETHYLENE
MIL compliance	YES
Plug contact pitch	0.109 inch
Match contact row spacing	0.112 inch
Installation option 1	M3
Installation option 2	INSERT
Installation method	STRAIGHT
Installation type	BOARD
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	2.8448 mm
Rated current (signal)	7.5 A
Guideline	UL
reliability	MIL-C-24308
Shell surface	TIN
Shell material	STEEL
Terminal length	0.217 inch
Terminal pitch	2.7686 mm
Termination type	SOLDER
Total number of contacts	25
Evacuation force-minimum value	.3058 N

Preview

Download Datasheet

View All

D-DF

D-Sub connectors - Screw-machined Contacts

FIXED MACHINED

CONTACT CONNECTOR

MAIN CHARACTERISTICS

DESCRIPTION

APPLICATIONS

Specifications

• UL File:

E64911

• Connectors according to:

MIL C24308 - NFC93425-HE5

Materials and platings

Shells

Steel yellow chromated over zinc or

tinned steel with or without dimples

on plug connector

Glass-filled thermoplastic, UL 94V-0

Brass, 3µm up to 5µm (118µ"up to 197µ")

tinned over nickel 2µm up to 3µm

(78µ" up to 118µ")

Tin-lead plating 4µm up to 6µm

(157µ" up to 236µ") over nickel 2µm up

to 3µm (78µ" up to 118µ")

Brass, 6µm up to 10µm (236µ" up to 394µ")

tinned over nickel 2µm up to 3µm

(78µ" up to 118µ")

brass

DF:

pin = brass

socket = copper alloy

Right angle version:

selective gold in

mating aréa over 2µm up to 3µm

(78µ" up to 118µ") nickel; 3µm up to

5µm (118µ" up to 197µ") tin-lead on

termination aréa over 2µm up to 3µm

(78µ" up to 118µ") nickel

Straight version:

full gold plating over

2µm up to 3µm (78µ" up to 118µ") nickel

Electrical Data

Current rating

Voltage rating

Withstanding voltage

Insulation resistance

Contact resistance

7.5 A

300 V AC/rms 50Hz

1000V AC/rms 50Hz for one minute

5000MΩ

8.5mΩ max

DF:

5mΩ max

Climatic Data

Operating temperature

-55°C to + 85°C (peaks at 125°C)

DF:

-55°C to +125°C

48 hours

21 days (40°C - 95% HR)

DF:

56 days (40°C - 95% HR)

Mechanical Data

Mating and unmating force

Unit: kg ( lb)

No. of Cts

9 (size E)

15 (size A)

25 (size B)

37 (size C)

50 (size D)

Mate (max)

3.05

5.09

8.44

12.51

14.65

(6.74)

(11.24)

(18.66)

(27.65)

(32.38)

Unmate (min)

0.36

0.46

0.81

1.1

1.6

(0.79)

(1.01)

(1.8)

(2.47)

(3.56)

Amphenol's 17D and 17DF series

fixed contact D-Subminiature

connector is suitable for industrial

or telecom use.

The machined contact provide

stability and reliability.

This series offers the broadest range

of termination options in the

Amphenol line.

Insulator

Rear insert

Boardlock

Screwlock

Contacts

Connectors

for industrial

and

telecom use

•

Industrial

•

Telecom

•

Any industry standard

I / O connections

E18/B

D-DF / E18
