Conformal Coated Axial Inductor
AICC-02
FEATURES:
• Ferrite core with Epoxy resin
• High current rating
• RoHS compliant
Pb
RoHS/RoHS II Compliant
APPLICATIONS:
• DC/DC converters
• Power supplies
• Electronic appliance
• Automotive system
6.22 x ϕ2.8 mm
STANDARD SPECIFICATIONS:
P ARAMETERS
ABRACON P/N:
Operating temperature:
Storage temperature:
Part No.
AICC-02-Inductance
Code
AICC-02-R27
AICC-02-R33
AICC-02-R39
AICC-02-R47
AICC-02-R56
AICC-02-R68
AICC-02-R82
AICC-02-1R0
AICC-02-1R2
AICC-02-1R5
AICC-02-1R8
AICC-02-2R2
AICC-02-2R7
AICC-02-3R3
AICC-02-3R9
AICC-02-4R7
AICC-02-5R6
AICC-02-6R8
AICC-02-8R2
AICC-02-100
AICC-02-120
AICC-02-150
AICC-02-180
AICC-02-220
AICC-02-270
AICC-02-330
AICC-02-390
AICC-02-470
AICC-02-560
AICC-02-680
AICC-02-820
AICC-02-101
AICC-02-121
AICC-02-151
AICC-02-181
AICC-02-221
AICC-02-271
AICC-02-331
AICC-02-391
AICC-02-471
AICC-02-561
AICC-02-681
AICC-02-821
AICC-02-102
L(µH)
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
AICC-02
-25°C ~ +105 °C
-40°C to + 125°C
Tolerance
(%)
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
Q (min)
40
40
40
40
40
40
40
40
40
45
50
50
50
50
45
45
45
40
40
40
45
40
50
50
50
50
50
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
L, Q Test
Freq.
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRF(MHz)
(min)
360
350
320
300
280
250
200
180
165
150
125
110
96
70
65
50
40
30
28
22
20
16
15
13
11
10
9.5
8.5
7.5
6.5
6.0
5.5
5.4
4.7
4.3
4.0
3.7
3.4
2.8
2.5
2.3
2.0
1.5
1.2
DCR(Ω)
(max)
0.08
0.08
0.09
0.10
0.11
0.12
0.12
0.15
0.18
0.20
0.23
0.25
0.28
0.30
0.32
0.35
0.40
0.45
0.72
0.80
0.88
1.00
1.20
1.35
1.50
1.70
2.30
2.60
2.90
3.20
3.50
3.80
4.40
5.00
6.50
9.50
10.5
11.6
13.0
18.0
23.0
26.0
20.0
20.0
I
DC
(mA)
(max)
1110
1110
1000
1000
950
900
900
815
740
700
655
630
595
575
555
560
500
470
425
370
350
335
315
285
270
255
240
205
195
185
175
165
160
150
140
130
120
100
95
90
85
75
65
60
ABRACON IS
ISO 9001 / QS 9000
ISO 9001:2008
CE RTIFIED
Revised: 09.04.12
30332
Esperanza, Rancho Santa
Margarita,
California 92688
tel 949-546-8000
|
fax
949-546-8001
|
www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
Conformal Coated Axial Inductor
AICC-02
TAPE & REEL:
Packing (5,000pcs / Reel)
Pb
RoHS/RoHS II Compliant
6.22 x ϕ2.8 mm
B
C
D
E
F
G
H
5+/-0.5
6+/-1.0
19 min
52+/-1.5
1.20 max
0.5 max
3.2
min
A
B
C
D
357+/-2
17+/-2
66+/-2
80+/-2
Dimension: mm
