MCC
Micro Commercial Components
TM
omponents
20736
Marilla
Street Chatsworth
!"#
$
% !"#
KBP2005
THRU
KBP210
2 Amp
Bridge Rectifier
50 to 1000 Volts
KBP
A
•
•
•
•
•
•
Features
Surge overload ratings 50 amperes peak
Electrically isolated base 1800Volts
Ideal for printed circuit board
UL Recognized File # E165989
Lead: Silver Plated Cooper Lead
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Maximum Ratings
•
•
•
Operating Temperature: -55°C to +125°C
Storage Temperature: -55°C to +150°C
2
I t
Rating for Fusing(t<8.3ms)
: 10
A
2
s
MCC
Catalog
Number
Device
Marking
Maximum
Recurrent
Peak
Reverse
Voltage
50V
100V
200V
400V
600V
800V
1000V
Maximum
RMS
Voltage
Maximum
DC
Blocking
Voltage
50V
100V
200V
400V
600V
800V
1000V
B
+
AC
-
KBP2005
KBP201
KBP202
KBP204
KBP206
KBP208
KBP210
KBP2005
KBP201
KBP202
KBP204
KBP206
KBP208
KBP210
35V
70V
140V
280V
420V
560V
700V
C
H
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum Forward
Voltage Drop Per
Element
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
I
F(AV)
I
FSM
2.0A
50A
T
A
= 55°C
8.3ms, half sine
G
E
D
V
F
1.1V
I
FM
= 1.0A per
element;
T
A
= 25°C*
T
J
= 25°C
T
J
= 100°C
DIMENSIONS
INCHES
MIN
---
---
.750
---
.150
.125
.320
MM
MIN
---
---
19.00
---
3.80
3.20
0.80
I
R
10µA
1mA
DIM
A
B
C
D
E
G
H
MAX
.693
.504
---
.250
---
---
MAX
17.60
12.80
---
6.40
---
---
NOTE
3PL/TYP
www.mccsemi.com
Revision: 4
1 of 3
2006/05/01
