KDZ2.0EVY: DescriptionZener Diode, 2.05V V(Z), 4.88%, 0.15W, Silicon, Unidirectional, ESC, 2 PIN; CategoryDiscrete semiconductor diode; File Size553KB，4 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/; Environmental Compliance

Download Datasheet Parametric View All

KDZ2.0EVY Overview

Zener Diode, 2.05V V(Z), 4.88%, 0.15W, Silicon, Unidirectional, ESC, 2 PIN

KDZ2.0EVY Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	KEC
package instruction	R-PDSO-F2
Contacts	2
Manufacturer packaging code	ESC
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	100 Ω
JESD-30 code	R-PDSO-F2
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.15 W
Certification status	Not Qualified
Nominal reference voltage	2.05 V
surface mount	YES
technology	ZENER
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	4.88%
Working test current	5 mA

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

CONSTANT VOLTAGE REGULATION APPLICATION.

REFERENCE VOLTAGE APPLICATION.

CATHODE MARK

KDZ2.0EV~36EV

ZENER DIODE

SILICON EPITAXIAL PLANAR DIODE

FEATURES

・Small

Package : ESC

・Sharp

Breakdown Characteristic.

MAXIMUM RATING (Ta=25℃)

CHARACTERISTIC

Power Dissipation

Junction Temperature

Storage Temperature Range

SYMBOL

stg

RATING

150

-55½150

UNIT

℃

* Mounted on a glass epoxy circuit board of 20×20㎜,

pad dimension of 4×4㎜.

DIM

MILLIMETERS

1.60 + 0.10

1.20 + 0.10

0.80 + 0.10

_ 0.05

0.30 +

0.60 + 0.10

0.13 + 0.05

0.20 + 0.10

ESC

Lot No.

Grade

None

Symbol

(Blank)

Grade **

Type No.

KDZ2.0EV

KDZ2.2EV

KDZ2.4EV

KDZ2.7EV

KDZ3.0EV

KDZ3.3EV

KDZ3.6EV

KDZ3.9EV

Marking

Type No.

KDZ4.3EV

KDZ4.7EV

KDZ5.1EV

KDZ5.6EV

KDZ6.2EV

KDZ6.8EV

KDZ7.5EV

KDZ8.2EV

Marking

Type No.

KDZ9.1EV

KDZ10EV

KDZ11EV

KDZ12EV

KDZ13EV

KDZ15EV

KDZ16EV

KDZ18EV

Marking

Type No.

KDZ20EV

KDZ22EV

KDZ24EV

KDZ27EV

KDZ30EV

KDZ33EV

KDZ36EV

Marking

2014. 3. 31

Revision No : 9

1/4
