NES5JAB1-FREQ4-20(T) datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> NES5JAB1-FREQ4-20(T)

NES5JAB1-FREQ4-20(T): DescriptionParallel - Fundamental Quartz Crystal, 32MHz Min, 50MHz Max, ROHS COMPLIANT, MINIATURE, CERAMIC, SMD, 2 PIN; CategoryPassive components Crystal/resonator; File Size297KB，2 Pages; ManufacturerPericom Semiconductor Corporation (Diodes Incorporated); Websitehttps://www.diodes.com/

Download Datasheet Parametric View All

NES5JAB1-FREQ4-20(T) Overview

Parallel - Fundamental Quartz Crystal, 32MHz Min, 50MHz Max, ROHS COMPLIANT, MINIATURE, CERAMIC, SMD, 2 PIN

NES5JAB1-FREQ4-20(T) Parametric

Parameter Name	Attribute value
Maker	Pericom Semiconductor Corporation (Diodes Incorporated)
package instruction	ROHS COMPLIANT, MINIATURE, CERAMIC, SMD, 2 PIN
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	AT-CUT CRYSTAL; TAPE AND REEL
Ageing	5 PPM/FIRST YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL
Drive level	10 µW
frequency stability	0.002%
frequency tolerance	20 ppm
load capacitance	20 pF
Manufacturer's serial number	NES5
Installation features	SURFACE MOUNT
Maximum operating frequency	50 MHz
Minimum operating frequency	32 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
physical size	L5.0XB3.2XH1.2 (mm)/L0.197XB0.126XH0.047 (inch)
Series resistance	40 Ω
surface mount	YES

Preview

Download Datasheet

View All

F9/FY Series

| Legacy NES5/NKS5 Series

5 x 3.2mm

Miniature

Quartz

Crystal

Ceramic

SMD

F9 FY

Actual Size

Frequency Range:

• 12.0000 MHz to 50.0000 MHz (Fundamental)

Product Description

The 2-pad F9 and the 4-pad FY Series devices

incorporate a sub-miniature AT-cut crystal resonator

housed in a standard 5x3.2mm ceramic package.

These compact crystals are ideal for surface mounting

in densely populated PCB applications.

Temperature Range:

• Operating: –20 to +70°C; –40 to +85°C (as specified)

• Storage: –40 to +85°C

Temperature Stability (as speciﬁed):

• ±10, ±20, ±30, ±50ppm (–20 to +70°C )

• ±30, ±50ppm (–40 to +85°C)

Product Features

• Rugged AT-cut crystal construction

• Miniature 5x3.2mm ceramic package

• Available on tape & reel; 12mm tape, 1000/reel

• FY: Pb-free and RoHS/Green compliant

• F9: RoHS compliant**

(** per #5, Annex of Directive 2002/05/EC)

Characteristics at 25°C ±2°C:

• Frequency Calibration Tolerance: ±10ppm, ±20ppm, ±30ppm

• Load Capacitance: 10 to 32pF or Series Resonance

• Effective Series Resistance:

70Ω max (12 to 12.9 MHz)

60Ω max (13 to 15.9 MHz)

50Ω max (16 to 31.9 MHz)

40Ω max (32 to 50 MHz)

• Drive Level: 10μW typ. (100μW max)

• Shunt Capacitance: 5pF Max.

Typical Applications

• HDD

• PCMCIA Cards

• Portable / hand-held PCs

• Notebook PC

• GPS

• Bluetooth

• Wireless LAN

• Portable Multimedia Devices

• USB Dongle

Aging at 25°C, First Year:

• ±3ppm Typ., ±5ppm Max.

Mechanical:

• Shock: JESD22-B104 (Condition B)

• Solderability: J-STD-002

• Vibration: JESD22-B103

• Solvent Resistance: JESD22-B107

• Resistance to Soldering Heat: J-STD-020C Table 5-2 Pb-free

devices (3 cycles max)

Environmental:

19.4400

20.0000

24.0000

24.5760

25.0000

26.0000

27.0000

32.7680

33.0000

40.0000

44.0000

48.0000

• Gross Test Leak: JESD22-A109 (Condition C)

• Fine Test Leak: JESD22-A109 (Condition A1)

• Moisture Resistance: JESD22-A113

Common Frequencies (MHz):

12.0000

13.5000

14.3181

14.7456

16.0000

18.4320

Reﬂow Temperature:

• 260°C Max (10 seconds max)

SaRonix-eCera™ is a Pericom® Semiconductor Corporation company • 1-800-435-2336 • www.pericom.com/saronix

All specifications are subject to change without notice.

DS 207 Rev C | 07/05/07
