ASMT-Ax3x
3W Power LED Light Source
Data Sheet
Description
This 3W power LED light source is a high-performance,
energy-efficient device that can handle high thermal and high
driving current. The exposed pad design enables excellent
heat transfer from the package to the motherboard. An option
with electrically isolated metal slug is also available.
The white power LED is available in the range of color
temperature from 2700K to 10000K.
The low profile package design is suitable for a wide variety of
applications especially where height is a constraint.
The package is compatible with reflow soldering process. This
part has a footprint that is compatible to most of the high
power LEDs in the market today.
Features
Available in red, red orange, amber, green, blue, royal blue,
cool white, neutral white, and warm white colors
Energy efficient
Exposed metal slug for excellent heat transfer
Compatible with reflow soldering process
High current operation
Long operation life
Wide viewing angle at 140°
Silicone encapsulation
Non-ESD sensitive (threshold > 16 kV)
MSL 2a products
Applications
Architectural lighting
Channel backlighting
Contour lighting
Retail display lighting
Decorative lighting
Garden lighting
Safety, exit, and emergency signs lighting
Specialty lighting
Task lighting
Broadcom
-1-
ASMT-Ax3x
Data Sheet
Figure 1 ASMT-Ax3x Package Outline Drawing
7.4
Ø 6.0
1.1
1.5
2.3
Ø 8.0
BOTTOM VIEW
7.4
Metal Slug
TOP VIEW
Anode
Lead
Lens
4.1 (ref.)
3.0
0.5
2.0
Cathode
Lead
6.0
13.8 0.2
Metal Slug
Body
NOTE
1.
2.
3.
4.
All dimensions in millimeters.
Metal slug is connected to anode for electrically non-isolated option.
Tolerance is ±0.1 mm unless otherwise specified.
Terminal finish: Ag plating.
Broadcom
-2-
ASMT-Ax3x
Data Sheet
Device Selection Guide (T
J
= 25°C)
Luminous Flux (lm) / Radiometric Power
Electrically
Test Current
Dice
(mW),
V a
,
b
Isolated
(mA)
Technology
Metal Slug
Min.
Typ.
Max.
51.7
39.8
39.8
67.2
87.4
Blue
Royal Blue
Cool White
Neutral White
Warm White
13.9
18.1
515 mW
99.6
113.6
87.4
60.0
50.0
50.0
78.0
105.0
18.0
23.0
600 mW
120.0
120.0
95.0
87.4
67.2
67.2
99.6
113.6
30.6
30.6
685 mW
147.7
147.7
129.5
350
350
350
350
350
350
350
350
350
350
350
AllnGaP
AllnGaP
AllnGaP
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
InGaN
No
c
No
c
No
c
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Part Number
Color
ASMT-AR30-AST00
ASMT-AH30-ARS00
ASMT-AA30-ARS00
ASMT-AG31-NTU00
ASMT-AG31-NUV00
ASMT-AB31-NMP00
ASMT-AB31-NNP00
ASMT-AL31-NRS00
ASMT-AW31-NVX00
ASMT-AN31-NWX00
ASMT-AY31-NUW00
a.
b.
c.
Flux and power tolerance is ±10 %.
Red
Red Orange
Amber
Green
V
is the total luminous flux/radiometric power output as measured with an integrating sphere at 25-ms mono pulse condition.
Electrically isolated metal slug option is also available. Contact your Broadcom sales representative.
Absolute Maximum Ratings
Parameter
DC Forward Current
a
Peak Pulsing Current
Power Dissipation
LED Junction Temperature
Operating Metal Slug Temperature Range at 350 mA
Operating Metal Slug Temperature Range at 700 mA
Storage Temperature Range
Soldering Temperature
Reverse Voltage
b
a.
b.
Derate linearly based on
Figure 13
and
Figure 14
for AlInGaP and
Figure 25
and
Figure 26
for InGaN.
Not recommended for reverse bias operation.
AllnGaP
700
1500
1820
125
–40 to +115
–40 to +100
–40 to +120
InGaN
700
2400
2730
135
–40 to +120
–40 to +105
–40 to +120
See
Figure 29
Not recommended
Units
mA
mA
mW
°C
°C
°C
°C
Broadcom
-3-
ASMT-Ax3x
Data Sheet
Optical Characteristics at 350 mA (T
J
= 25°C)
Peak
Wavelength,
PEAK
(nm)
Typ.
ASMT-AR30-AST00
ASMT-AH30-ARS00
ASMT-AA30-ARS00
ASMT-AG31-NTU00
ASMT-AG31-NUV00
ASMT-AB31-NMP00
ASMT-AB31-NNP00
ASMT-AL31-NRS00
a.
b.
Part Number
Color
Dominant
Wavelength,
Da
(nm)
Typ.
625
615
590
525
525
460
460
455
Viewing Angle,
Luminous
b
(°)
Efficiency (lm/W)
2
½
Typ.
140
140
140
140
140
140
140
140
Typ.
82
68
68
70
94
16
21
Not applicable
Red
Red Orange
Amber
Green
Blue
Royal Blue
635
625
598
519
519
454
454
450
The dominant wavelength,
D
, is derived from the CIE Chromaticity Diagram and represents the color of the device.
½
is the off-axis angle where the luminous intensity is half of the peak intensity.
Part Number
Color
Correlated Color Temperature, CCT
(Kelvin)
Min.
Max.
10000
4500
3500
Viewing Angle,
Luminous
a
Efficiency (lm/W)
2
½
(°)
Typ.
140
140
140
Typ.
107
107
85
ASMT-AW31-NVX00
ASMT-AN31-NWX00
ASMT-AY31-NUW00
a.
Cool White
Neutral White
Warm White
4500
3500
2700
½
is the off-axis angle where the luminous intensity is half of the peak intensity.
Electrical Characteristic at 350 mA (T
J
= 25°C)
Forward Voltage, V
F
(Volts)
Dice Type
Min.
AllnGaP
InGaN
a.
Thermal Resistance, R
j-ms
(°C/W)
a
Max.
2.3
3.5
Typ.
10
10
Typ.
2.1
3.2
1.7
2.8
R
j-ms
is thermal resistance from LED junction to metal slug.
Broadcom
-4-
ASMT-Ax3x
Data Sheet
Optical and Electrical Characteristic at 700 mA (T
J
= 25°C)
Part Number
Color
Luminous Flux (lm)/Radiometric
Power (mW),
V
Typ.
ASMT-AR30-AST00
ASMT-AH30-ARS00
ASMT-AA30-ARS00
ASMT-AG31-NTU00
ASMT-AG31-NUV00
ASMT-AB31-NMP00
ASMT-AB31-NNP00
ASMT-AL31-NRS00
ASMT-AW31-NVX00
ASMT-AN31-NWX00
ASMT-AY31-NUW00
Royal Blue
Cool White
Neutral White
Warm White
Blue
Red
Red Orange
Amber
Green
112.0
94.0
94.0
125.0
168.0
30.0
39.0
1022 mW
205.0
205.0
162.0
Forward Voltage, V
F
(Volts)
Typ.
2.4
2.4
2.4
3.6
3.6
3.6
3.6
3.6
3.6
3.6
3.6
Part Numbering System
A
S
M
T
-
A
x
1
3
x
2
-
x
3
x
4
x
5
x
6
Code
x
1
Description
Color
Option
R
H
A
G
B
L
W
N
Y
Red
Red-Orange
Amber
Green
Blue
Royal Blue
Cool White
Neutral White
Warm White
Electrically Non Isolated
Electrically Isolated
InGaN
AlInGaP
x
2
x
3
x
4
x
5
x
6
x
7
Heat sink
Dice Type
Minimum Flux Bin
Maximum Flux Bin
Color Bin Selection
Packaging Option
0
1
N
A
See Device Selection Guide
See Color Bin Selection Table
0
1
Tube
Tape and Reel
Broadcom
-5-
