Electrical / Environmental
•
•
•
•
Operating Temperature Range
-40°C to +130°C
Ambient Temperature, Maximum
80°C
Insulation System Class F, 155°C
Operating Frequency
Up to 3MHz
High Current Low Profile Surface Mount Inductors
HM65
S
RoH
liant
mp
Co
Specifications / Packaging
Part
Number
HM65-H1R0LF
HM65-H1R8LF
HM65-H2R8LF
HM65-H3R9LF
HM65-H4R0LF
HM65-H5R6LF
HM65-H6R0LF
HM65-H7R2LF
HM65-1R5LF
HM65-2R5LF
HM65-6R0LF
HM65-8R2LF
HM65-100LF
HM65-P1R0LF
HM65-P1R2LF
HM65-P1R8LF
HM65-P2R5LF
HM65-M0R5LF
HM65-M0R8LF
HM65-M2R5LF
Notes:
Inductance
(1)
Nominal
Rated DC Current
(2)
µH
(Amps)
±
20%
25°C
130°C
1.0
1.8
2.8
3.9
4.0
5.6
6.0
7.2
1.5
2.5
6.0
8.2
10.0
1.0
1.2
1.8
2.5
0.5
0.8
2.5
20.0
15.3
12.3
10.5
10.3
8.8
8.0
7.8
14.0
10.0
6.7
5.8
5.0
20.0
18.0
16.0
10.0
29.0
20.0
12.0
13.5
11.5
10.5
8.3
8.0
7.5
6.5
6.0
10.5
8.0
4.5
4.5
4.0
20.0
18.0
16.0
10.0
24.0
16.0
10.0
Heating
Current
(3)
(Amps)
19.9
15.2
12.1
11.4
11.4
8.1
8.1
7.8
17.1
15.2
11.5
8.1
7.8
19.9
19.9
15.2
15.2
16.3
16.3
9.3
DC Resistance
m
W
m
W
Typ.
Max.
1.7
2.9
4.6
5.2
5.2
10.2
10.2
11.4
1.7
2.9
5.1
10.2
11.3
1.7
1.7
2.9
2.9
1.8
1.8
5.5
2.5
3.4
5.4
8.0
8.0
11.4
11.4
13.5
2.5
3.4
8.0
11.4
13.5
2.5
2.5
3.4
3.4
2.2
2.2
6.0
(4)
Ht
Height
mm
Case Size
Max.
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Mini
Mini
Mini
5.6
5.6
5.6
5.6
5.6
5.6
5.6
6.0
5.6
5.6
5.6
5.6
5.6
6.0
6.0
6.0
6.0
5.6
5.6
5.6
13” Reel
Qty
(Units)
400
400
400
400
400
400
400
400
400
400
400
400
400
400
400
400
400
500
500
500
(1) Inductance is measured at 100kHz, 0.1V without DC current.
(2) Rated DC current is the approximate current at which inductance will be decreased by 25% from its initial (zero DC) value.
(3) Heating current is the DC current which causes the inductor temperature to increase by approximately 40°C.
(4) DC resistance is measured at 25°C.
Outline Dimensions (mm)
Top View
Side View
Bottom View
C
BI HM65 – XXXXLF
YYWW MALAYSIA
Recommended
Solder Pad Layout
DUMMY
TERMINAL
I
P
J
L
A Max.
D 1
H
D
Ht
Refer to Specifications
Table
2
3
E
B Max.
F
G
M
K
N
Case Size
Standard
Mini
A
12.5
10.4
B
13.5
10.4
C
7.3
6.7
D
2.6
2.6
E
2.6
1.5
F
2.6
2.3
G
2.6
1.1
H
7.4
5.5
I
13.9
10.8
J
4.4
2.5
K
6.9
6.5
L
3.0
1.8
M
3.8
2.8
N
3.2
1.5
P
3.0
3.0
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
59
We reserve the right to change specifications without prior notice.
Electrical Characteristics @ 25°C
Ordering Information
HM65 - H
Model Series
Type:
H = High Current
P = Premium Core Material
M = Mini-Package
1R0
LF
TR13
TR - Tape & Reel Packing
13 - 13” reel
Lead-Free
Inductance Code:
First 2 digits are significant. Last digit denotes the
number of trailing zeros. For values below 10µH, “R“
