HD48125FP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> HD48125FP

HD48125FP: DescriptionTrigger Output SSR, 1-Channel, 4000V Isolation, ROHS COMPLIANT, PLASTIC PACKAGE-4; CategoryLED optoelectronic/LED photoelectric; File Size836KB，5 Pages; ManufacturerCrydom; Websitehttp://www.crydom.com/en/index.shtml; Environmental Compliance

Download Datasheet Parametric View All

HD48125FP Overview

Trigger Output SSR, 1-Channel, 4000V Isolation, ROHS COMPLIANT, PLASTIC PACKAGE-4

HD48125FP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Crydom
package instruction	ROHS COMPLIANT, PLASTIC PACKAGE-4
Reach Compliance Code	compliant
Other features	UL RECOGNIZED, VDE APPROVED, ZERO VOLTAGE CROSSING
Configuration	SINGLE
Maximum insulation voltage	4000 V
JESD-609 code	e3
Number of components	1
Maximum on-state current	125 A
Maximum operating temperature	80 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRIGGER OUTPUT SSR
Terminal surface	Tin (Sn)

Preview

Download Datasheet

View All

HA / HD48 Series

• Ratings from 12A to 125A @ 48-530 VAC

• SCR output for heavy industrial loads

• AC or DC control

• Zero-crossing (resistive loads) or random-fire (inductive loads) output

PRODUCT SELECTION

Control Voltage

3-32 VDC

90-280 Vrms

18-36 Vrms

90-280 Vrms

12A

HD4812

HA4812

HA4812E

HA4812

25A

HD4825

HA4825

HA4825E

HA4825

50A

HD4850

HA4850

HA4850E

HA4850

75A

HD4875

HA4875

HA4875E

HA4875

90A

HD4890

HA4890

HA4890E

HA4890

110A

HD48110

HA48110

HA48110E

HA48110

125A

HD48125

HA48125

HA48125E

HA48125

AVAILABLE OPTIONS

OUTPUT SPECIFICATIONS (1)

Description

Operating Voltage (47-63Hz) [Vrms]

Transient Overvoltage [Vpk]

Maximum Off-State Leakage Current @ Rated Voltage [mArms]

Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec] (2)

Maximum Load Current (3) [Arms]

Minimum Load Current [mArms]

Maximum Surge Current (16.6ms) [Apk]

Maximum On-State Voltage Drop @ Rated Current [Vpk]

Thermal Resistance Junction to Case (Rjc) [°C/W]

Maximum I

t for Fusing (8.3 msec) [A

sec]

Minimum Power Factor (with Maximum Load)

12A

48-530

1200

500

140

1.7

1.48

0.5

25A

48-530

1200

500

250

1.7

1.02

260

0.5

50A

48-530

1200

500

625

1.7

0.63

1620

0.5

75A

48-530

1200

500

1000

1.7

0.31

4150

0.5

90A

48-530

1200

500

1200

1.7

0.28

6000

0.5

110A

48-530

1200

500

110

150

1500

1.7

0.25

9340

0.5

125A

48-530

1200

500

125

150

1750

1.7

0.22

12700

0.5
