• 1N4099 THRU 1N4135 AVAILABLE IN
JANHC AND JANKC
PER MIL-PRF-19500/435
• ZENER DIODE CHIPS
• ALL JUNCTIONS COMPLETELY PROTECTED WITH SILICON DIOXIDE
• 0.5 WATT CAPABILITY WITH PROPER HEAT SINKING
• ELECTRICALLY EQUIVALENT TO 1N4099 THRU 1N4135
• COMPATIBLE WITH ALL WIRE BONDING AND DIE ATTACH TECHNIQUES,
WITH THE EXCEPTION OF SOLDER REFLOW
CD4099
thru
CD4135
MAXIMUM RATINGS
Operating Temperatures: -65°C to +175°C
Storage Temperatures: -65°C to +175°C
Forward Voltage @ 200 mA: 1.5 Volts maximum
23 MILS
15 MILS
CDI
TYPE
NUMBER
NOMINAL
ZENER
VOLTAGE
V @I
Z
ZT
(Note 1)
VOLTS
ZENER
TEST
CURRENT
I
ZT
MAXIMUM
ZENER
IMPEDANCE
Z
ZT
(Note 2)
MAXIMUM REVERSE
LEAKAGE CURRENT
I @V
R
R
µ
A
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
OHMS
200
200
200
200
200
200
200
200
200
200
100
100
100
100
150
150
150
150
150
150
200
200
200
200
200
250
250
300
300
400
500
700
700
800
1000
1200
1500
µ
A
10.0
10.0
1.0
1.0
1.0
1.0
.05
.05
.05
.05
.05
.05
.05
.05
.05
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
.01
VOLTS
5.17
5.70
6.24
6.61
6.92
7.60
8.44
9.12
9.87
10.65
11.40
12.15
12.92
13.67
14.44
15.20
16.72
18.25
19.00
20.46
21.28
22.80
25.08
27.38
29.65
32.56
35.75
38.76
42.60
45.60
47.10
51.68
57.00
62.32
66.12
69.16
76.00
CD4099
CD4100
CD4101
CD4102
CD4103
CD4104
CD4105
CD4106
CD4107
CD4108
CD4109
CD4110
CD4111
CD4112
CD4113
CD4114
CD4115
CD4116
CD4117
CD4118
CD4119
CD4120
CD4121
CD4122
CD4123
CD4124
CD4125
CD4126
CD4127
CD4128
CD4129
CD4130
CD4131
CD4132
CD4133
CD4134
CD4135
6.8
7.5
8.2
8.7
9.1
10
11
12
13
14
15
16
17
18
19
20
22
24
25
27
28
30
33
36
39
43
47
51
56
60
62
68
75
82
87
91
100
Backside is Cathode
FIGURE 1
DESIGN DATA
METALLIZATION:
Top: (Anode)..................... ...Al
Back:(Cathode)...................Au
AL THICKNESS............25,000
Å
Min
GOLD THICKNESS...
.....4,000
Å
Min
CHIP THICKNESS............
......10 Mils
CIRCUIT LAYOUT DATA:
For Zener operation, cathode
must be operated positive with
respect to anode.
TOLERANCES:
ALL
Dimensions + 2 mils
NOTE 1
Zener voltage range equals nominal Zener voltage + 5% for no suffix types.
Zener voltage is read using a pulse measurement, 10 milliseconds maximum.
"C" suffix = + 2% and "D" suffix = + 1%.
NOTE 2
Zener impedance is derived by superimposing on lZT A
60Hz rms a.c. current equal to 10% of lZT.
22 COREY STREET, MELROSE, MASSACHUSETTS 02176
PHONE (781) 665-1071
FAX (781) 665-7379
WEBSITE: http://www.cdi-diodes.com
E-mail: mail@cdi-diodes.com
15 MILS
ELECTRICAL CHARACTERISTICS
@ 25°C, unless otherwise specified.
23 MILS
