S-1711A3033-I6T1GG datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> S-1711A3033-I6T1GG

S-1711A3033-I6T1GG: DescriptionFixed Positive LDO Regulator, 2 Output, 3V1, 3.3V2, CMOS, PDSO6, LEAD FREE, SNT-6; CategoryPower/power management The power supply circuit; File Size521KB，44 Pages; ManufacturerABLIC; Environmental Compliance

Download Datasheet Parametric View All

S-1711A3033-I6T1GG Overview

Fixed Positive LDO Regulator, 2 Output, 3V1, 3.3V2, CMOS, PDSO6, LEAD FREE, SNT-6

S-1711A3033-I6T1GG Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ABLIC
Parts packaging code	SOIC
package instruction	VSOF,
Contacts	6
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum drop-back voltage 1	0.35 V
Maximum drop-back voltage 2	0.35 V
Maximum input voltage	6.5 V
Minimum input voltage	2 V
JESD-30 code	R-PDSO-F6
JESD-609 code	e6
length	1.6 mm
Number of functions	1
Output times	2
Number of terminals	6
Maximum output voltage 1	3.03 V
Minimum output voltage 1	2.97 V
Nominal output voltage 1	3 V
Maximum output voltage 2	3.333 V
Minimum output voltage 2	3.267 V
Nominal output voltage 2	3.3 V
Package body material	PLASTIC/EPOXY
encapsulated code	VSOF
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Regulator type	FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Maximum seat height	0.5 mm
surface mount	YES
technology	CMOS
Terminal surface	TIN BISMUTH
Terminal form	FLAT
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	1.57 mm

Preview

Download Datasheet

View All

S-1711 Series

www.sii-ic.com

SUPER-SMALL PACKAGE 2-CIRCUIT HIGH RIPPLE-REJECTION

LOW DROPOUT CMOS VOLTAGE REGULATOR

Rev.3.0

_00

The S-1711 Series is a 2-channel positive voltage regulator with a low dropout voltage, high output voltage accuracy, and

low current consumption (150 mA output current) developed based on CMOS technology.

A 1.0

μF

small ceramic capacitor can be used, and a 2-circuit voltage regulator with

±1.0%

high-accuracy output voltage is

incorporated in an SOT-23-6 or super-small SNT-6A package. The A/ B/ E/ F types are provided with a discharge shunt

function allowing high-speed output response when the ON/OFF pin is used.

Compared with the conventional 150 mA output current 2-channel CMOS voltage regulators, high-density mounting is

realized by using the super-small SNT-6A package and a small ceramic capacitor. Also, the low current consumption

makes the S-1711 Series ideal for mobile devices.

Features

1.5 V to 5.5 V, selectable in 0.1 V steps.

A ceramic capacitor of 1.0

μF

or more can be used for the output capacitor.

2.0 V to 6.5 V

±1.0%

200 mV typ. (3.0 V output product, I

OUT

150 mA)

During operation:

μA

typ., 90

μA

max. (Per circuit)

During shutdown: 0.1

μA

typ., 1.0

μA

max.

150 mA output is possible (at V

≥

OUT(S)

1.0 V)

(Per circuit)

•

Output current:

•

High ripple rejection:

70 dB typ. (at 1.0 kHz)

•

Built-in overcurrent protector:

Overcurrent of output transistor can be restricted.

•

Built-in ON/OFF circuit:

Ensures long battery life.

•

Discharge shunt circuit can be selected.

•

Pull-down or pull-down resistor can be selected.

•

Lead-free, Sn 100%, halogen-free

*1.

Attention should be paid to the power dissipation of the package when the output current is large.

*2.

Refer to “

Product Name Structure”

for details.

•

Output voltage:

•

Low ESR capacitor can be used:

•

Wide input voltage range:

•

High-accuracy output voltage:

•

Low dropout voltage:

•

Low current consumption:

Applications

•

Power supply for cellular phones

•

Power supply for battery-powered devices

•

Power supply for home electric/electronic appliances

Packages

•

SNT-6A

•

SNT-23-6

Seiko Instruments Inc.
