ISS-P-15-A-L-4: DescriptionIsolator, SC/APC Connector; CategoryWireless rf/communication Optical fiber; File Size218KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

ISS-P-15-A-L-4 Overview

Isolator, SC/APC Connector

ISS-P-15-A-L-4 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Connection Type	SC/APC CONNECTOR
Fiber optic equipment types	ISOLATOR
Fiber type	SMF-28
Maximum insertion loss	0.5 dB
Minimum isolation	22 dB
Maximum operating temperature	70 °C
Minimum operating temperature
Nominal operating wavelength	1550 nm
Maximum optical input power	500 mW
minimum return loss	55 dB

Preview

Download Datasheet

View All

Isolator

Polarization Insensitive Single Stage Isolator

Parameter

Central Wavelength

Bandwidth

Isolation in Band (at 23° C)

Isolation in Band (0-70° C)

Insertion Loss (at 23° C)

Insertion Loss in Band(0-70° C)

Return Loss (Input/Output)

PDL

PMD

Maximum Power

Operating Temperature

Storage Temperature

Package Dimensions

Note1: All values specified are without connectors.

Note2: Higher performance specifications upon request.

Note3: Fiber type Corning SMF-28e.

Premium

± 15nm

≥ 32 dB

≥ 22 dB

≤ 0.4 dB

≤ 0.5 dB

≥ 60/55 dB

≤ 0.05 dB

≤ 0.2 ps

500 mW

0° C ~ + 70° C

A Grade

1310 nm, 1480 nm or 1550 nm

≥ 30 dB

≥ 20 dB

≤ 0.5 dB

≤ 0.7 dB

≥ 60/55 dB

≤ 0.1 dB

- 40° C ~ + 85° C

5.5 mm () x 35 mm (L)

I S S -

Grade

P: Premium

A: A Grade

Center Wavelength

13: 1310 nm

14: 1480 nm

15: 1550 nm

Fiber Length

A: 1 meter

S: Special

Pigtail Style

(=Package style)

B: bare fiber

L: 900

m

loose tube

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
