LMax DIP Power Inductor
LMDP Series –Shielded Style P
FEATURES
• Density design, small size, and low cost
• Comparatively range rated current and high inductance
• Low DCR and high dip stability
CHARACTERISTICS
• Rated DC Current: The current when the inductance
becomes 10% lower than its initial value. (Ta=25°C)
• Operating temperature range -40
~ 100°C
APPLICATIONS
• Personal Computers
• Variety of Battery Power Equipment
• DC Power Supply Circuits
INDUCTANCE AND RATED
CURRENT RANGES
• 0606
22 ~ 1000μH
0.96 ~ 0.14A
• 0807
22 ~ 10000μH
1.60 ~ 0.074A
• 1008
10 ~ 1000μH
2.80 ~ 0.28A
• 1010
10 ~ 1000μH
3.51 ~ 0.35A
• Electrical specifications at 25°C
DIMENSIONS
LMDP 0606 / 0807
B
C
E
A
LMDP 1008 / 1010
B
C
E
D
A
D1
D
P
mm (inches)
Type
0606
0807
1008
1010
A
6.00 ± 0.50
(0.236 ± 0.020)
7.80 ± 0.50
(0.307 ± 0.020)
10.0 ± 0.50
(0.394 ± 0.020)
10.0 ± 0.5
(0.394 ± 0.020)
B max.
6.50
(0.256)
7.50
(0.295)
8.50
(0.335)
10.5
(0.413)
4.00
(0.157
5.00
(0.197
3.50
(0.138
3.5
(0.138
C
± 1.00
± 0.039)
± 1.00
± 0.039)
± 1.00
± 0.039)
± 1.0
± 0.039)
4.00
(0.157
5.00
(0.197
5.00
(0.197
5.0
(0.197
D
± 0.30
± 0.012)
± 0.30
± 0.012)
± 0.30
± 0.012)
± 0.3
± 0.012)
D1
–
–
4.00
(0.157
4.0
(0.157
±
±
±
±
0.30
0.012)
0.3
0.012)
E
0.50 ± 0.10
(0.010 ± 0.004)
0.65 ± 0.10
(0.026 ± 0.004)
0.65 ± 0.10
(0.026 ± 0.004)
0.70 ± 0.1
(0.028 ± 0.004)
P
–
–
6.40 ± 0.50
(0.252 ± 0.020)
6.40 ± 0.5
(0.252 ± 0.020)
HOW TO ORDER
LM
Family
LM = Power Inductor
DP
Series
DP = DIP
0606
Size
0606 = 6x6xh
0807 = 8x7xh
1008 = 10x8xh
1010 = 10x10xh
(h = see catalog)
M
Tolerance
K = ±10%
M = ±20%
101
Inductance
100 = 10μH
101 = 100μH
102 = 1000μH
103 = 10000μH
P
Style
T
Termination
T = Sn Plate
A
Special
A = Standard
B
Packaging
B = Box
56
LMax DIP Power Inductor
LMDP Series –Shielded Style P
ELECTRICAL CHARACTERISTICS
0606/0807/1008/1010
Codes
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
L
(μH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
Tolerance
M
M
M
M
M
M
M
M
M
M
M
M
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
Test
Condition
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
100KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
1KHz, 0.1V
0606
–
–
–
–
0.13
0.18
0.21
0.26
0.29
0.33
0.36
0.39
0.54
0.62
0.72
0.88
0.99
1.52
1.69
1.85
2.85
3.21
3.60
4.87
5.56
–
–
–
–
–
–
–
–
–
–
–
–
DCR (Ω) max.
0807
1008
–
0.05
–
0.06
–
0.07
–
0.08
0.08
0.09
0.10
0.10
0.14
0.11
0.15
0.12
0.17
0.14
0.19
0.15
0.21
0.16
0.27
0.18
0.32
0.20
0.36
0.24
0.51
0.35
0.57
0.40
0.76
0.54
0.86
0.76
0.97
0.86
1.28
0.93
1.44
1.23
1.61
1.34
2.07
1.53
2.33
2.10
2.72
2.30
3.98
–
4.50
–
6.81
–
7.56
–
8.54
–
9.74
–
12.90
–
14.70
–
20.40
–
23.00
–
30.60
–
35.00
–
1010
0.023
0.024
0.036
0.039
0.042
0.045
0.057
0.076
0.100
0.110
0.150
0.160
0.190
0.210
0.230
0.260
0.290
0.360
0.510
0.690
0.980
1.100
1.200
1.300
1.500
–
–
–
–
–
–
–
–
–
–
–
–
0606
–
–
–
–
0.96
0.87
0.78
0.72
0.66
0.60
0.55
0.50
0.45
0.41
0.37
0.34
0.30
0.27
0.25
0.23
0.21
0.19
0.17
0.16
0.14
–
–
–
–
–
–
–
–
–
–
–
–
I sat (A) max*
0807
1008
–
2.80
–
2.50
–
2.30
–
2.10
1.60
2.00
1.40
1.76
1.30
1.60
1.20
1.38
1.10
1.28
0.99
1.20
0.89
1.00
0.81
0.96
0.74
0.92
0.67
0.80
0.60
0.73
0.55
0.64
0.50
0.61
0.45
0.56
0.41
0.50
0.37
0.44
0.34
0.41
0.31
0.38
0.28
0.34
0.26
0.32
0.23
0.28
0.21
–
0.19
–
0.17
–
0.16
–
0.14
–
0.13
–
0.12
–
0.11
–
0.099
–
0.089
–
0.081
–
0.074
–
1010
3.51
3.24
2.88
2.61
2.34
2.16
1.89
1.80
1.62
1.44
1.35
1.26
1.08
0.99
0.90
0.82
0.74
0.67
0.61
0.55
0.51
0.46
0.42
0.38
0.35
–
–
–
–
–
–
–
–
–
–
–
–
*Saturation Current: The current when the inductance becomes 10% lower than its initial value. (Ta=25°C)
