Engineering Development Model
Band Pass Filter
Surface Mount
Important Note
This model has been designed, built and tested in our engineering
department. Performance data represents model capability.
At present it is a non-catalog model. On request, we can supply a
final specification sheet, part number and price/delivery information.
Please click "Back", and then click "Contact Us" for Applications support.
BPF-EDU1002
CASE STYLE : HU1186
ELECTRICAL SPECIFICATIONS 50Ω @ +25°C
Min.
Typ.
Max.
141
184.5
DC
118
261
261
1.2
20
118
124
925
4500
1.6
228
Parameter
Passband
(Loss < 3 dB)
Centre frequency
Low Band (Loss > 40 dB)
Low Band (Loss > 20 dB)
High Band (Loss > 55 dB)
High Band (Loss > 25 dB )
Passband VSWR
Stopband VSWR
Units
MHz
MHz
MHz
MHz
MHz
MHz
(:1)
(:1)
Functional Schematic
MAXIMUM RATINGS
Operating Temperature
Storage Temperature
RF Power Input
-40°C to 85°C
-55°C to 100°C
10mW
PIN CONNECTIONS
Input
Output
Not Connected
Case Ground
2
9
6,13
1,3,4,5,7,8,10,11,12,14
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
EW
ALL N
minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
REV. X1
BPF-EDU1002
URJ
080627
Page 1 of 1
