JS6MFKTV3: DescriptionPower/Signal Relay, 1 Form A, SPST, Momentary, 0.038A (Coil), 6VDC (Coil), 225mW (Coil), 8A (Contact), 24VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size181KB，9 Pages; ManufacturerFUJITSU; Websitehttp://edevice.fujitsu.com/fmd/en/index.html; Environmental Compliance

Download Datasheet Parametric View All

JS6MFKTV3 Overview

Power/Signal Relay, 1 Form A, SPST, Momentary, 0.038A (Coil), 6VDC (Coil), 225mW (Coil), 8A (Contact), 24VDC (Contact), DC Input, AC/DC Output, Through Hole-Straight Mount, ROHS COMPLIANT

JS6MFKTV3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	FUJITSU
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
body width	10 mm
body height	12.5 mm
Body length or diameter	29 mm
Maximum coil current (DC)	0.038 A
Coil operating voltage (DC)	4.2 V
Coil power	225 mW
Coil release voltage (DC)	0.6 V
Coil resistance	160 Ω
Maximum coil voltage (DC)	6 V
Nominal coil voltage	6 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	8A@250VAC
Maximum contact current (AC)	8 A
Maximum contact current (DC)	8 A
Contact (DC) maximum rated R load	8A@24VDC
Maximum contact voltage (AC)	250 V
Maximum contact voltage (DC)	24 V
Contact/Output Power Type	AC/DC
Dielectric strength between coil and contacts	4000 Vrms
Dielectric strength between breaking contacts	1000 Vrms
Electrical life	200000 Cycle(s)
Insulation resistance	1000000000 Ω
JESD-609 code	e4
Installation features	THROUGH HOLE-STRAIGHT MOUNT
Number of terminals	4
operating hours	10 ms
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PCB hole count	4
physical size	29mm x 10mm x 12.5mm
Guideline	BSI; CSA; FIMKO; OVE; SEMKO; SEV; UL; VDE
Relay action	MOMENTARY
Relay style	1 FORM A
Relay function	SPST
Relay type	POWER/SIGNAL RELAY
release time	5 ms
seal	PLASTIC SEALED
surface mount	NO
Terminal surface	Gold (Au)
Terminal length	0.003 inch
Termination type	SOLDER
weight	8 g

Preview

Download Datasheet

View All

POWER RELAY

1 POLE—8 A

(MEDIUM LOAD CONTROL)

Lead Free / RoHS compliant*

JS SERIES

FEATURES

UL, CSA, VDE, SEV, SEMKO, FIMKO, ÖVE, BSI

recognized

UL class B (130°C) insulation

1 form A (SPST-NO) or 1 form C (SPDT) contact

Low profile and space saving—Height: 12.5 mm

—Mounting space: 290 mm

High sensitivity in small package

—Operating power ............ 0.11 to 0.14 W

—Nominal power ............... 0.22 to 0.29 W

High isolation in small package

—Insulation distance : 8 mm

—Dielectric strength : 5,000 VAC

(between coil and contacts)

—Surge strength

: 10,000 V

Plastic materials—UL 94 flame class V-0

—UL CTI level class 2

Plastic sealed type

Lead Free since date code: 0438B9, 0434R - Please see page 6 for more information

* some part numbers still contain cadmium and are not RoHS compliant

ORDERING INFORMATION

[Example]

(a)

(b)

(c)

(d)

JS – 12

(a) (*) (b)

(c)

E – K

(d)

(e)

T – V3

(f)

(j)

Series Name

Nominal Voltage

Contact Arrangement

Contact Material

JS : JS Series

Refer to the COIL DATA CHART

Nil : 1 form C (SPDT)

M : 1 form A (SPST-NO)

Nil : Gold plate silver cadmium oxide

D : Silver nickel

E : Silver cadmium oxide

F : Silver nickel gold overlay

N : Silver tin oxide gold overlay

K : Plastic sealed type

Nil: 3.2 mm

T : 5.0 mm (only JS-MN, MD, MF)

Nil: 0.3µ gold overlay (available with Nil, N and F contact)

V3: 3µ gold overlay for lower current applications (available with Nil, N

and F contact)

(e)

(f)

(j)

Enclosure

Construction

For low current application

Note: Actual marking omits the hyphen (-) of (*)
