Production
Sockets
Specifications
Series IC160
PLCC (SMT)
Part Number
(Details)
500MΩ min. at 500V DC
250V AC for 1 minute
30mΩ max. at 10mA / 20mV
1A max.
-55°C ~ +85°C
220°C max. at 60 secs. max / 260° Peak
0.147 N / Pin min., 1.47 N / Pin max.
20 insertions max.
Insulation Resistance:
Withstanding Voltage:
Contact Resistance:
Current Rating:
Operating Temperature Range:
Soldering Temperature:
Insertion/Extraction Force:
Mating Cycles:
IC160Z
Series No.
–
020 4 – ** 0 1
No. of Contact Pins
No. of Sides with Contacts
Terminal Style
24 = Inside Leads (Type 1)
30 = Outside Leads (Type 2)
0 = Without Positioning Pin
1 = With Positioning Pin
Packaging:
Unmarked =Tray
1 = Embossed Tape
2 = Tube
Materials and Finish
Housing: PA, glass filled, UL94V-0 rated
Contact: Copper Alloy, SnBi (3.0 ~ 7.0µm) plating
Features
Low profile design (5.0 and 4.6mm height)
2 different terminal styles available
Designed for automatic mounting (SMT type)
INFO
For PLCC DIP (TH) versions (1C160Z-****400)
Please contact Yamaichi
Available Body Forms
Height Dimension Square Form
(both terminal types)
Height Dimension Rectangle Form
(both terminal types)
Square
Rectangle
Available Terminal Types
IC160Z-0**4-24** (Type1)
IC160Z-0**4-30** (Type 2)
1)
2)
For pins 20, 28, 44
For pins 52, 68, 84
For pins 32 only
For pins 20, 28, 44, 52, 68, 84
For pins 32 only
Connectors
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
Series IC160
PLCC (SMT)
Outline Socket Dimensions Terminal Type 1
A
C
1.27±0.1
Production
Sockets
Outline Socket Dimensions Terminal Type 2
A
C
1.27±0.1
BB
1.27±0.1
B
D
D
B
0.50±0.1
AA
Recommended PCB Layout
F
E
Top View from Socket
*Dimensions for X
IC160Z-0324-301 =
17.78
IC160Z-0324-3011 =
17.78
IC160Z-0444-301 =
20.32
IC160Z-0444-3011 =
20.32
All other part numbers have no pin locator holes
C
X*
H
G
D
Part Number
IC160Z-0204-240
IC160Z-0204-2401
IC160Z-0204-300
IC160Z-0204-3001
IC160Z-0284-240
IC160Z-0284-2401
IC160Z-0284-3001
IC160Z-0324-240
IC160Z-0324-2401
IC160Z-0324-2402
IC160Z-0324-300
IC160Z-0324-301
IC160Z-0324-3011
IC160Z-0444-240
IC160Z-0444-2401
IC160Z-0444-300
IC160Z-0444-301
IIC160Z-0684-240
IC160Z-0684-2401
IC160Z-0684-300
IC160Z-0684-3001
IC160Z-0844-240
IC160Z-0844-2401
IC160Z-0844-300
IC160Z-0844-3001
Pin
Count
20
20
20
20
28
28
28
32
32
32
32
32
32
44
44
44
44
68
68
68
68
84
84
84
84
A
14.46
14.46
14.46
14.46
17.00
17.00
17.00
19.50
19.50
19.50
19.50
19.50
19.50
22.08
22.08
22.08
22.08
30.30
30.30
30.30
30.30
35.58
35.58
35.58
35.58
AA
-
-
16.06
16.06
-
-
18.60
-
-
21.10
21.10
21.10
-
-
23.68
23.68
-
-
31.30
31.30
-
-
36.38
36.38
B
14.46
14.46
14.46
14.46
17.00
17.00
17.00
17.00
17.00
17.00
17.00
17.00
17.00
22.08
22.08
22.08
22.08
30.30
30.30
30.30
30.30
35.58
35.58
35.58
35.58
BB
-
-
16.06
16.06
-
-
18.60
-
-
-
18.60
18.60
18.60
-
-
23.68
23.68
-
-
31.30
31.30
-
-
36.38
36.38
C
5.08
5.08
5.08
5.08
7.62
7.62
7.62
10.16
10.16
10.16
10.16
10.16
10.16
12.70
12.70
12.70
12.70
20.32
20.32
20.32
20.32
25.40
25.40
25.40
25.40
D
5.08
5.08
5.08
5.08
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
12.70
12.70
12.70
12.70
20.32
20.32
20.32
20.32
25.40
25.40
25.40
25.40
E
6.27
6.27
12.26
12.26
8.81
8.81
14.80
11.35
11.35
11.35
17.30
17.30
17.30
13.89
13.89
19.88
19.88
21.51
21.51
27.50
27.50
26.59
26.59
32.58
32.58
F
10.27
10.27
17.06
17.06
12.81
12.81
19.60
15.35
15.35
15.35
22.10
22.10
22.10
17.89
17.89
24.68
24.68
25.51
25.51
32.30
32.30
30.59
30.59
37.38
37.38
J
6.27
6.27
12.26
12.26
8.81
8.81
14.80
8.81
8.81
8.81
14.80
14.80
14.80
13.89
13.89
19.88
19.88
21.51
21.51
27.50
27.50
26.59
26.59
32.58
32.58
Connectors
H
10.27
10.27
17.06
17.06
12.81
12.81
19.60
12.81
12.81
12.81
19.60
19.60
19.60
17.89
17.89
24.68
24.68
25.51
25.51
32.30
32.30
30.59
30.59
37.38
37.38
SPECIFICATIONS AND DRAWINGS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE - DIMENSIONS IN MILLIMETER
