PJ16A40Z datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> PJ16A40Z

PJ16A40Z: DescriptionRectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-220AB, TO-220, 3 PIN; CategoryDiscrete semiconductor diode; File Size151KB，2 Pages; ManufacturerPromax-Johnton Electronic Corporation

Download Datasheet Parametric Compare View All

PJ16A40Z Overview

Rectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-220AB, TO-220, 3 PIN

PJ16A40Z Parametric

Parameter Name	Attribute value
Maker	Promax-Johnton Electronic Corporation
Parts packaging code	TO-220AB
package instruction	R-PSFM-T3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	EFFICIENCY
Shell connection	ANODE
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
Maximum non-repetitive peak forward current	150 A
Number of components	2
Phase	1
Number of terminals	3
Maximum output current	16 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	40 V
surface mount	NO
technology	SCHOTTKY
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

Preview

Download Datasheet

View All

! "#"

$#"!%

$#"#!

&#!

$#"!##'()*(+,-(.#"(%,*/#.

0 1#"#"21 "#!!!!!

#(%!" !)#!"" 13$4110

!1%5

6 78 1#

6 )#

6;<=8##

1#0 <)0#

780 )#<:*#") 1

!!,? ; < ".

6>0 #7#>

A@(

,B*.

1# 1<A

;<=8##!<A

A!A" ,B.

A!?<!,B.

D!#A! #

)#A! #

BDA )'A" ?<

)

$4!!11#91

**7C";5

(

((

(

(E(

3(E(

<<"3<9<

PJ16A40Z Related Products

	PJ16A40Z	PJ16C40Z	PJ16C40M	PJ16A40M
Description	Rectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-220AB, TO-220, 3 PIN	Rectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-220AB, TO-220, 3 PIN	Rectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-263AA, TO-263, 4 PIN	Rectifier Diode, Schottky, 1 Phase, 2 Element, 16A, 40V V(RRM), Silicon, TO-263AA, TO-263, 4 PIN
Maker	Promax-Johnton Electronic Corporation	Promax-Johnton Electronic Corporation	Promax-Johnton Electronic Corporation	Promax-Johnton Electronic Corporation
Parts packaging code	TO-220AB	TO-220AB	D2PAK	D2PAK
package instruction	R-PSFM-T3	R-PSFM-T3	R-PSSO-G3	R-PSSO-G3
Contacts	3	3	4	4
Reach Compliance Code	unknown	unknown	unknown	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99
Other features	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE
application	EFFICIENCY	EFFICIENCY	EFFICIENCY	EFFICIENCY
Shell connection	ANODE	CATHODE	CATHODE	ANODE
Configuration	COMMON ANODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JEDEC-95 code	TO-220AB	TO-220AB	TO-263AA	TO-263AA
JESD-30 code	R-PSFM-T3	R-PSFM-T3	R-PSSO-G3	R-PSSO-G3
Maximum non-repetitive peak forward current	150 A	150 A	150 A	150 A
Number of components	2	2	2	2
Phase	1	1	1	1
Number of terminals	3	3	3	3
Maximum output current	16 A	16 A	16 A	16 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLANGE MOUNT	FLANGE MOUNT	SMALL OUTLINE	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	40 V	40 V	40 V	40 V
surface mount	NO	NO	YES	YES
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING
Terminal location	SINGLE	SINGLE	SINGLE	SINGLE
