Zener Diode Chip Series
CD4728A thru CD4764A
Features
•
•
•
•
All junctions completely protected with silicon dioxide
1.0 Watt capability with proper heat sinking
Electrically equivalent to 1N4728A thru 1N4764A
Compatible with all wire bonding and die attach
techniques with the exception of solder reflow.
Maximum Ratings
Operating Temperature:
Storage Temperature:
-65°C to +175°C
-65°C to +175°C
Forward Voltage @ 200mA: 1.5 volts maximum
Electrical Specifications @ +25 ºC (Unless Otherwise Specified)
TYPE
NUMBER
NOMINAL
ZENER
VOLTAGE
VZ @ IZT
(NOTE 1)
VOLTS
CD4728A
CD4729A
CD4730A
CD4731A
CD4732A
CD4733A
CD4734A
CD4735A
CD4736A
CD4737A
CD4738A
CD4739A
CD4740A
CD4741A
CD4742A
CD4743A
CD4744A
CD4745A
CD4746A
CD4747A
CD4748A
CD4749A
CD4750A
CD4751A
CD4752A
CD4753A
CD4754A
CD4755A
CD4756A
CD4757A
CD4758A
CD4759A
CD4760A
CD4761A
CD4762A
CD4763A
CD4764A
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10.0
11.0
12.0
13.0
15.0
16.0
18.0
20.0
22.0
24.0
27.0
30.0
33.0
36.0
39.0
43.0
47.0
51.0
56.0
462.0
68.0
75.0
82.0
91.0
100.0
mA
76
69
64
58
53
49
45
41
37
34
31
28
25
23
21
29
17
15.5
14
12.5
11.5
10.5
9.5
8.5
7.5
7.0
6.5
6.0
5.5
5.0
4.5
4.0
3.7
3.3
3.0
2.8
2.5
ZENER
TEST
CURRENT
l ZT
MAXIMUM
ZENER
IMPEDANCE
ZZT @ l ZT
(NOTE 2)
OHMS
10
10
9
9
8
7
5
2
3.5
4
4.5
5
7
8
9
10
14
16
20
22
23
25
35
40
45
50
60
70
80
95
110
125
150
175
200
250
350
MAXIMUM
REVERSE
CURRENT
IR @ V R
IR
μA
100
100
100
10
10
5
5
5
3
3
3
3
3
2
1
0.5
0.1
0.1
0.1
0.1
0.1
O.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
VOLTS
1
1
1
1
1
1
2
3
4
5
6
7
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
56.0
62.2
69.2
76.0
TEST
FACTOR
VR
MAXIMUM
KNEE
IMPEDANCE
ZZK
(NOTE 2)
OHMS
400
400
400
400
500
550
600
700
700
700
700
700
700
700
700
700
700
700
750
750
750
750
750
1000
1000
1000
1000
1500
1500
1500
2000
2000
2000
2000
3000
3000
3000
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
TEST
CURRENT
IZK
NOTE 1
NOTE 2
Zener voltage range equals nominal Zener voltage. + 5% for “A” Suffix. No Suffix denotes + 10 %. Zener voltage is
read using a pulse measurement, 10 milliseconds maximum. "C" suffix = + 2% and "D" suffix = + 1%.
Zener impedance is derived by superimposing on lZT a 60Hz rms ac current equal to 10 % of IZT.
Revision Date: 6/4/2014
New Product
1
CD4728A thru CD4764A
Outline Drawing
DESIGN DATA
METALLIZATION:
Anode
AL THICKNESS:
GOLD THICKNESS:
CHIP THICKNESS:
Top:
Back:
(Anode) Al
(Cathode) Au
25,000 Å Minimum
4,000 Å Minimum
10 Mils
CIRCUIT LAYOUT DATA: For Zener operation, cathode must
be operated positive with respect to anode.
