IC120 Series
(Open Top)
Plastic Lead Chip Carrier
(PLCC)
Specifications
1,000M
W
min. at 500V DC
Insulation Resistance:
Dielectric Withstanding Voltage: 700V AC for 1 minute
30m
W
max. at 10mA/20mV max.
Contact Resistance:
1A max.
Current Rating:
Operating Temperature Range: –40°C to +170°C
10,000 insertions min.
Mating Cycles:
Part Number
(Details)
IC120
Series No.
-
068 4
-
0 04 MF
No. of Contact Pins
Number of Sides
with Contacts
Terminal Arrangement
and IC Orientation
(see table below)
Design Number
MF = Flanged
Unmarked = Not Flanged
Note:
Mounting Flange is not available for 18 pins, 22 pins
and IC120-0684-304
Materials and Finish
Housing: Upper body – Polyphenylenesulfide (PPS)
Lower body – Polyetherimide (PEI), glass-filled
Contacts: Beryllium Copper (BeCu)
Plating: Gold over Nickel
Features
í
Two-point contacts and a larger contact width ensures high reliability
í
Auto-ejecting type for automated operation (IC is inserted in "one touch"
operation and pushing the cover raises it for easy IC removal)
í
Available for two types of IC orientation (Live-bug & Dead-bug)
Outline Socket Dimensions
Inserting Direction of IC
DB
= Dead-bug
0.35 x 0.25
LB
= Live-bug
IC
Part Number
Pin
Count
Insert.
IC120-0324-009
IC120-0324-109
*IC120-0324-209
*IC120-0324-309
IC120-0324-409
IC120-0324-509
IC120-0444-006
IC120-0444-106
*IC120-0444-206
*IC120-0444-306
IC120-0444-406
IC120-0444-506
IC120-0524-007
IC120-0524-107
*IC120-0524-207
*IC120-0524-307
IC120-0524-407
IC120-0524-507
IC120-0684-004
IC120-0684-104
*IC120-0684-204
*IC120-0684-304
IC120-0684-404
IC120-0684-504
IC120-0844-003
IC120-0844-103
*IC120-0844-203
*IC120-0844-303
IC120-0844-403
IC120-0844-503
32
32
32
32
32
32
44
44
44
44
44
44
52
52
52
52
52
52
68
68
68
68
68
68
84
84
84
84
84
84
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
Socket Dim.
A
B
C
22.5
22.5
22.5
22.5
22.5
22.5
28.0
28.0
28.0
28.0
28.0
28.0
30.0
30.0
30.0
30.0
30.0
30.0
35.0
35.0
35.0
35.0
35.0
35.0
40.0
40.0
40.0
40.0
40.0
40.0
25.0
25.0
25.0
25.0
25.0
25.0
28.0
28.0
28.0
28.0
28.0
28.0
30.0
30.0
30.0
30.0
30.0
30.0
35.0
35.0
35.0
35.0
35.0
35.0
40.0
40.0
40.0
40.0
40.0
40.0
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
Test & Burn-In
C
B
Dead-bug type
* Most compatible socket type
A
Live-bug type
IC
Part Number
Pin
Count
Insert.
*IC120-0184-002
*IC120-0184-102
IC120-0184-202
IC120-0184-302
IC120-0204-005
*IC120-0204-205
IC120-0204-405
*IC120-0224-001
*IC120-0224-101
IC120-0224-201
IC120-0224-301
IC120-0284-008
IC120-0284-108
*IC120-0284-208
*IC120-0284-308
IC120-0284-408
*IC120-0284-508
18
18
18
18
20
20
20
22
22
22
22
28
28
28
28
28
28
DB
LB
DB
LB
DB
DB
DB
DB
LB
DB
LB
DB
LB
DB
LB
DB
LB
Socket Dim.
A
C
B
17.0
17.0
17.0
17.0
20.0
20.0
20.0
17.0
17.0
17.0
17.0
23.0
23.0
23.0
23.0
23.0
23.0
21.5
21.5
21.5
21.5
20.0
20.0
20.0
21.5
21.5
21.5
21.5
23.0
23.0
23.0
23.0
23.0
23.0
18.0
19.3
18.0
19.3
18.0
18.0
18.0
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
18.0
19.3
SPECIFICATIONS ARE SUBJECT TO ALTERATION WITHOUT PRIOR NOTICE – DIMENSIONS IN MILLIMETER
