T-1 (3mm) SOLID STATE LAMP
L-934SURC-E
HYPER RED
Features
!
LOW
Description
The Hyper Red source color devices are made with DH
InGaAlP on GaAs substrate Light Emitting Diode.
PURPOSE LEADS.
AND RUGGED.
ON TAPE AND REEL.
POWER CONSUMPTION.
!
GENERAL
!
RELIABLE
!
LONG
LIFE - SOLID STATE RELIABILITY.
!
AVAILABLE
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAB0737
APPROVED: J.Lu
REV NO: V.2
CHECKED:Allen Liu
DATE: JAN/08/2003
DRAWN: F.Y.YUAN
PAGE: 1 OF 3
Selection Guide
Par t No .
Dic e
L en s Ty p e
Iv (m c d )
@ 20 m A
Min .
L-934SURC-E
HYPER RED (InGaAlP)
WATER CLEAR
900
Ty p .
1300
V i ew i n g
An g l e
2θ1/2
50 °
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
Par am et er
Peak Wavelength
Dominate Wavelength
Spectral Line Half-width
Capacitance
Forward Voltage
Reverse Current
D ev i c e
Hyper Red
Hyper Red
Hyper Red
Hyper Red
Hyper Red
Hyper Red
Ty p .
640
6 30
25
45
1.9
2.5
10
Max .
Un it s
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
H y p e r R ed
15 0
30
200
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un it s
mW
mA
mA
V
SPEC NO: DSAB0737
APPROVED: J.Lu
REV NO: V.2
CHECKED:Allen Liu
DATE: JAN/08/2003
DRAWN: F.Y.YUAN
PAGE: 2 OF 3
