T-1 (3mm) HYPER RED LED LAMPS
Features
HYPER BRIGHTNESS.
OUTSTANDING MATERIAL EFFICIENCY.
RELIABLE AND RUGGED.
I.C. COMPATIBLE.
L934SURC HYPER RED
L934SURC/E HYPER RED
Package Dimensions
Description
The Hyper Red (SUR) source color devices are made
with DH InGaAlP on GaAs substrate Light Emitting Diode.
The Hyper Red (SUR/E)source color devices are made
with DH InGaAlP on GaAs substrate Light Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
Selection Guide
Par t No .
Di c e
L en s Ty p e
Iv (mc d )
@ 20 mA
Min .
L934SURC
L934SURC/E
HYPER RED (InGaAlP)
HYPER RED (InGaAlP)
WATER CLEAR
WATER CLEAR
500
1000
Ty p .
1300
1300
View in g
An g l e
2θ1/2
50°
50°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
SPEC NO: DSAA0171
REV NO: V.1
DATE: MAR/13/2001
PAGE: 1 OF 3
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
Par ameter
Peak Wavelength
Dev ic e
Hyper Red (SUR)
Hyper Red (SUR/E)
Ty p .
640
640
25
25
35
30
2.0
2.45
10
2.2
2.6
Max .
Un i t s
nm
Tes t Co n d itio n s
IF=20mA
∆λ
1/2
Hyper Red (SUR)
Spectral Line Halfwidth Hyper Red (SUR/E)
Capacitance
Hyper Red (SUR)
Hyper Red (SUR/E)
Hyper Red (SUR)
Hyper Red (SUR/E)
Hyper Red (SUR)
Hyper Red (SUR/E)
nm
IF=20mA
C
pF
VR=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
VR = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Hy p er Red (SUR)
170
50
150
5
Hy p er Red (SUR/E)
120
40
150
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un i t s
mW
mA
mA
V
SPEC NO: DSAA0171
REV NO: V.1
DATE: MAR/13/2001
PAGE: 2 OF 3
