DATA SHEET
E.S.D NOISE CLIPPING DIODES
NNCD3.3F to NNCD12F
ELECTROSTATIC DISCHARGE NOISE CLIPPING DIODES
(DOUBLE TYPE, ANODE COMMON)
3PIN MINI MOLD
This product series is a diode developed for E.S.D (Electrostatic
Discharge) noise protection. Based on the IEC1000-4-2 test on
electromagnetic interference (EMI), the diode assures an endur-
PACKAGE DIMENSIONS
(in millimeters)
0.4
–0.05
2.8 ± 0.2
1.5
0.65
–0.15
+0.1
external interface circuit protection.
Type NNCD3.3F to NNCD12F Series include two elements in
0.95 0.95
2.9 ± 0.2
3PIN Mini Mold Package having allowable power dissipation of
200 mW.
+0.1
ance of no less than 30 kV, thus making itself most suitable for
2
1
3
FEATURES
• Based on the electrostatic discharge immunity test (IEC1000-4-
2), the product assures the minimum endurance of 30 kV.
• Based on the reference supply of the set, the product achieves
a series over a wide range (15 product name lined up).
1.1 to 1.4
0.3
Marking
0.16
–0.06
+0.1
APPLICATIONS
• External interface circuit E.S.D protection.
• Circuits for Waveform clipper, Surge absorber.
PIN CONNECTION
SC-59 (EIAJ)
1. K1: Cathode 1
2. K2: Cathode 2
3. A : Anode (common)
K2
2
MAXIMUM RATINGS (T
A
= 25
°
C)
Power Dissipation
Surge Reverse Power
Junction Temperature
Storage Temperature
P
P
RSM
T
j
T
stg
200 mW
100 W (t
T
= 10
µ
s 1 pulse)
150
°C
–55
°C
to +150
°C
(Total)
Fig. 6
0 to 0.1
0.4
–0.05
+0.1
A
3
K1
1
Document No. D11774EJ2V0DS00 (2nd edition)
Date Published December 1996 N
Printed in Japan
©
1996
