IMC-0402
Vishay Dale
High Frequency, Surface Mount, Laser Spiral, Coated Inductors
FEATURES
• Very small size
• High self-resonant frequency values
• High Q values relative to size at higher
frequencies
• Coated coil provides protection and moisture
resistance
• Compatible with vapor phase and infrared reflow
soldering
• Tape and reel packaging for automatic handling,
10 000/reel, EIA-481
• L and Q value not affected by mounting orientation
• Compliant to RoHS Directive 2002/95/EC
• Halogen-free according to IEC 61249-2-21 definition
STANDARD ELECTRICAL SPECIFICATIONS
TEST
FREQ.
(MHz)
TOL.
L
Q
RATED
SRF DCR
DC
Q
MIN. MAX. CURRENT
MIN. (MHz) ()
(mA)
(1)
21
21
21
21
21
21
21
20
20
20
19
19
19
19
19
19
19
19
18
18
17
17
15
15
14
6000
6000
6000
6000
6000
5500
5500
5200
4800
4600
4000
3500
2800
2800
2500
2200
2000
1800
1800
1800
1800
1500
1500
1400
1200
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.19
0.30
0.35
0.41
0.45
0.60
0.70
0.80
1.20
1.40
1.70
2.10
2.50
4.00
4.50
5.50
400
400
400
400
400
400
400
360
360
340
320
320
320
320
240
240
200
200
170
150
140
130
120
110
90
IND.
(nH)
1.0 0.3 nH, 0.2 nH 100 800
1.2 0.3 nH, 0.2 nH 100 800
1.5 0.3 nH, 0.2 nH 100 800
1.8 0.3 nH, 0.2 nH 100 800
2.2 0.3 nH, 0.2 nH 100 800
2.7 0.3 nH, 0.2 nH 100 800
3.3 0.3 nH, 0.2 nH 100 800
3.9 0.3 nH, 0.2 nH 100 800
4.7 0.3 nH, 0.2 nH 100 800
5.6 0.3 nH, 0.2 nH 100 800
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
5%
5%
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
100 800
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 nH to 100 nH
Inductance and Tolerance:
± 0.3 nH for 1.0 nH to 5.6 nH,
± 5 % for 6.8 nH to 100 nH
Operating Temperature:
- 40 °C to + 100 °C
Core Material:
Ceramic
TEST EQUIPMENT
• Inductance and Q measured on HP4291B
• SRF measured on HP8753E
• DCR measured on HP4338B
DIMENSIONS
in inches [millimeters]
0.008 [0.2]
0.020 ± 0.004
[0.5 ± 0.1]
0.039 ± 0.004
[1.0 ± 0.1]
0.020 ± 0.004
[0.5 ± 0.1]
Solder Pad Layout
0.02 [0.50]
0.020 [0.50]
0.063 [1.60]
Note
(1)
Value obtained when current flows and temperature has risen 15 °C
DESCRIPTION
IMC-0402
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
Document Number: 34038
Revision: 23-Feb-11
C
0
4
SIZE
0
2
E
R
1
0
N
J
TOL.
PACKAGE
CODE
INDUCTANCE
VALUE
