IMC-0805
Vishay Dale
High Frequency, Surface Mount, Molded Inductors
FEATURES
• High self-resonant frequency values
• High Q values at higher frequencies
• Molded construction provides superior strength
and moisture resistance
• Wirewound construction
• Compatible with vapor phase and infrared reflow
soldering
• Tape and reel packaging for automatic handling,
3000/reel, EIA-481
• Compliant to RoHS Directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
TEST
FREQ.
(MHz)
TOL.
10 %
10 %
10 %
10 %
10 %
10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
5 %, 10 %
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
RATED
DC
SRF DCR
Q TYP. (MHz)
Q
MIN. ± 30 % CURRENT
L & Q MIN. 100 800 1800 (MHz) ()
(mA)
10
10
12
12
15
15
15
15
15
15
15
15
8
8
10
10
10
10
10
10
10
10
10
10
8
22
22
23
25
25
25
28
28
28
28
28
28
25
24
25
25
25
25
20
20
18
15
-
-
-
65 110 3300
65 105 3300
70 100 3000
75 95 3000
75 80 2600
75 - 2500
80 - 2050
70 - 2000
70 - 1650
60 - 1550
-
- 1450
-
- 1100
-
-
800
-
-
600
-
-
600
-
-
600
-
-
500
-
-
300
-
-
200
-
-
150
-
-
150
-
-
100
-
-
100
-
-
80
-
-
80
0.14
0.18
0.18
0.22
0.22
0.26
0.30
0.31
0.35
0.39
0.44
0.48
0.66
0.76
1.13
1.24
1.41
1.50
1.66
1.82
1.97
2.07
2.32
2.60
2.98
540
535
520
480
465
455
395
390
385
360
340
330
285
275
230
195
170
165
160
150
145
140
130
125
120
ELECTRICAL SPECIFICATIONS
Inductance Range:
10 nH to 1000 nH
Inductance and Tolerance:
± 10 % for 10 nH to 1000 nH,
± 5 % for 33 nH to 1000 nH
Operating Temperature:
- 40 °C to + 105 °C (no load)
- 40 °C to + 85 °C (at full rated current)
Core Material:
Non-magnetic
IND.
(nH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
TEST EQUIPMENT
• Inductance and Q measured on HP4191A
• SRF measured on HP8753B
DIMENSIONS
in inches [millimeters]
0.078 + 0.012 - 0.008
[2.00 + 0.3 - 0.2]
0.049 ± 0.012
[1.25 ± 0.3]
0.049 ± 0.012
[1.25 ± 0.3]
0.016 ± 0.008
[0.4 ± 0.2]
0.039 ± 0.004
[1.0 ± 0.1]
Recommended Pad Layout
0.043 ± 0.004
[1.1 ± 0.1]
0.043 ± 0.008
[1.1 ± 0.2]
0.134 ± 0.016
[3.4 ± 0.4]
Note
• Tighter tolerance product may be substituted based on availability.
DESCRIPTION
IMC-0805
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
Document Number: 34040
Revision: 23-Feb-11
C
0
8
SIZE
0
5
E
R
1
0
N
J
TOL.
PACKAGE
CODE
INDUCTANCE
VALUE
