LC877356A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> LC877356A

LC877356A: DescriptionMicrocontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP100, QIP-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size525KB，26 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric Compare View All

LC877356A Overview

Microcontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP100, QIP-100

LC877356A Parametric

Parameter Name	Attribute value
Maker	SANYO
Parts packaging code	QFP
package instruction	QFP,
Contacts	100
Reach Compliance Code	unknown
Has ADC	YES
Other features	ALSO AVAILABLE IN TQFP-100 PACKAGE; ALSO OPERATES AT 2.5V MINIMUM SUPPLY
Address bus width
bit size	8
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PQFP-G100
length	20 mm
Number of I/O lines	89
Number of terminals	100
Maximum operating temperature	70 °C
Minimum operating temperature	-30 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Not Qualified
ROM programmability	MROM
Maximum seat height	3 mm
speed	10 MHz
Maximum supply voltage	6 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Ordering number : ENN*7157

CMOS IC

LC877372A/64A56A/48A

8-Bit Single Chip Microcontroller

LC877372A

8 bit Single Chip Microcontroller incorporating 72KB ROM and 2048 byte RAM on chip

LC877364A

8 bit Single Chip Microcontroller incorporating 64KB ROM and 2048 byte RAM on chip

LC877356A

8 bit Single Chip Microcontroller incorporating 56KB ROM and 2048 byte RAM on chip

LC877348A

8 bit Single Chip Microcontroller incorporating 48KB ROM and 2048 byte RAM on chip

Overview

The LC877372A, LC877364A LC877356A and LC877348A are 8-bit single chip microcontrollers with the

following on-chip functional blocks :

- CPU: operable at a minimum bus cycle time of 100 ns

- On-chip ROM Maximum Capacity : LC877372A 72K bytes

LC877364A 64K bytes

LC877356A 56K bytes

LC877348A 48K bytes

- On-chip RAM capacity: 2048 bytes

- LCD controller / driver

- 16 bit timer / counter (can be divided into two 8 bit timers)

- 16 bit timer / PWM (can be divided into two 8 bit timers)

- Four 8-bit timer with prescalers

- Timer for use as date / time clock

- Synchronous serial I/O port (with automatic block transmit / receive function)

- Asynchronous / synchronous serial I/O port

- 15-channel × 8-bit AD converter

- Small signal detector

Ver:1.03

M2003.

M2003 Nothing (Nothing) SK No.7157-1/26

LC877356A Related Products

	LC877356A	LC877372A
Description	Microcontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP100, QIP-100	Microcontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP100, QIP-100
Maker	SANYO	SANYO
Parts packaging code	QFP	QFP
package instruction	QFP,	QFP,
Contacts	100	100
Reach Compliance Code	unknown	unknown
Has ADC	YES	YES
Other features	ALSO AVAILABLE IN TQFP-100 PACKAGE; ALSO OPERATES AT 2.5V MINIMUM SUPPLY	ALSO AVAILABLE IN TQFP-100 PACKAGE; ALSO OPERATES AT 2.5V MINIMUM SUPPLY
bit size	8	8
maximum clock frequency	20 MHz	20 MHz
DAC channel	NO	NO
DMA channel	NO	NO
JESD-30 code	R-PQFP-G100	R-PQFP-G100
length	20 mm	20 mm
Number of I/O lines	89	89
Number of terminals	100	100
Maximum operating temperature	70 °C	70 °C
Minimum operating temperature	-30 °C	-30 °C
PWM channel	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	QFP
Package shape	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified
ROM programmability	MROM	MROM
Maximum seat height	3 mm	3 mm
speed	10 MHz	10 MHz
Maximum supply voltage	6 V	6 V
Minimum supply voltage	4.5 V	4.5 V
Nominal supply voltage	5 V	5 V
surface mount	YES	YES
technology	CMOS	CMOS
Temperature level	OTHER	OTHER
Terminal form	GULL WING	GULL WING
Terminal pitch	0.65 mm	0.65 mm
Terminal location	QUAD	QUAD
width	14 mm	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER
