HCMOS 7x5mm SMD Oscillator
•
HCMOS Output
•
Stabilities to ±20 PPM
•
Temperature Ranges as
•
Supply Voltages:
5.0V
O7HH
(former F3345 Series)
DATASHEET
wide as
-40ºC
to +85ºC
5.0V ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
01.000 ~ 25.000 MHz
25.000+ ~ 50.000 MHz
50.000+ ~ 67.000 MHz
67.000+ ~ 80.000 MHz
80.000+ ~ 125.000 MHz
Output Symmetry (50% V
DD
)
Rise/Fall Time (10%/
90
% V
DD
Levels) (T
R
/T
F
)
1.000
~
125.000
MHz
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
(HCMOS)
Start-up Time
(T
S
)
Output Disable Time
1
Output Enable Time
1
ENABLE / DISABLE FUNCTION
Pin1
Output (pin 3)
OPEN
1
Active
Active
‘1’ Level V
IH
≥
70%V
DD
High Z
‘0’ Level V
IL
≤
30%V
DD
MAX
(unless otherwise noted)
1
~
125
MHz
-55 ~ +125°C
5.0
±10%
25
mA
40
mA
60 mA
73 mA
90 mA
45
% ~
55
%
7
nS
10
% V
DD
90
% V
DD
Min
16
mA Min
-16 mA Min
50
pF
10
mS
100
nS
100 nS
•
Available Options by Stability & Operating Temp for 5.0V
2
Frequency
Stability
2
±100PPM
±100PPM
±50PPM
±50PPM
±25PPM
±25PPM
±20PPM*
1
2
Operating
Temperature (ºC)
Frequency Range (MHz)
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
1.000 ~ 125.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
1.000 ~ 80.000
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
Seal Method
Lead (Pb) Free
ROHS/REACH Compliant
260°C / 10 Seconds
1
Au over Ni
Seam Seal
Yes
Yes
An internal pull-up resistor from pin 1 to pin 4 allows active output if pin 1 is left open
Inclusive of 25°C tolerance, operating temperature range, input voltage change, load change, reflow, and one year aging. *Excludes Shock/Vibration.
Notes:
A 0.01μF capacitor should be placed between V
DD
(Pin 4) and GND (Pin2) to minimize power supply line noise.
Dimensional drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may vary
© Copyright 2017 Fox Electronics, All rights reserved
Title / Description:
O7HH SERIES STANDARD SPECIFICATIONS
Drawing Number:
101164
Size: A
Cage:
61429
Part Number:
Draftsperson:
MK
Approved:
RB
Revision Date:
08/23/2017
Page
1
of
2
HCMOS 7x5mm SMD Oscillator
Tape Specifications (millimeters)
B
C
D
E
F
Std Reel Qty
4.0
8.0
7.5
16.0
2.15
2,000
O7HH
(former F3345 Series)
DATASHEET
Reel Specifications (millimeters)
H
I
J
K
L
Ф13 Ф21 Ф80 Ф255 17.5
A
Ф1.5
G
2.0
M
2.0
Available Options & Part Identification*
Example: F O7HH A B M 25.0
F
Fox
O7HH
Model Number
A
Voltage
A = 5V±10%
B
Stability
A = 100 PPM
B = 50 PPM
D = 25 PPM
E = 20 PPM
M
Operating
Temperature
E = -10 to +70°C
M = -40 to +85°C
25.0
Frequency
*Not all frequencies in the frequency range, or every combination of stability, temp range, and voltage available. See stabilities and op temps on page 1.
Corporate Headquarters
5570 Enterprise Parkway
Fort Myers, FL 33905
http://www.FOXONLINE.com
1-888-GET-2-FOX (1-888-438-2369)
or
1-239-693-0099
http://www.FOXONLINE.com/repdisty
Sales
http://www.FOXONLINE.com/email
Tech Support
Product use:
Fox Electronics reserves the right to modify the products and/or specifications described herein at any time and at Fox Electronics'
sole discretion. All information in this document, including descriptions of product features and performance, is subject to change without notice.
Performance specifications and the operating parameters of the described products are determined in the independent state and are not
guaranteed to perform the same way when installed in customer products. The information contained herein is provided without representation or
warranty of any kind, whether express or implied, including, but not limited to, the suitability of Fox Electronics' products for any particular purpose,
an implied warranty of merchantability, or non-infringement of the intellectual property rights of others. This document is presented only as a guide
and does not convey any license under intellectual property rights of Fox Electronics or any third parties.
Fox Electronics' products are not intended for use in applications involving extreme environmental conditions or in life support systems or
similar devices where the failure or malfunction of a Fox Electronics product can be reasonably expected to significantly affect the health or
safety of users. Anyone using a Fox Electronics product in such a manner does so at their own risk, absent an express, written agreement by
Fox Electronics.
Fox Electronics and the Fox logo are registered trademarks of Fox Electronics. Product specification is subject to change without notice.
Other trademarks and service marks used herein, including protected names, logos and designs, are the property of Fox Electronics or their
respective third party owners.
Title / Description:
O7HH SERIES STANDARD SPECIFICATIONS
Drawing Number:
101164
Size: A
Cage:
61429
Part Number:
Draftsperson:
MK
Approved:
RB
Revision Date:
08/23/2017
© Copyright 2017 Fox Electronics, All rights reserved
Page
2
of
2
