Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SDR3006HF series
1/
DESIGNER’S DATA SHEET
Part Number / Ordering Information
SDR30 __ HF __ __ __
│ │ │ │ └
Screening
__
= Not Screened
TX = TX Level
│ │ │ │
TXV = TXV
│ │ │ │
S = S Level
│ │ │ │
│ │ │ └
Lead Options
__
= Straight Leads
DB = Down Bend
│ │ │
UB = Up Bend
│ │ │
│ │ └
Package
M = TO-254
│ │
Z = TO-254Z
│ │
│ └
Configuration hyperfast family
│
│
└
Voltage
04 = 400 V
05 = 500 V
06 = 600 V
30A 35nsec
400 to 600 V
Hyper Fast Rectifier
Features
:
•
•
•
•
•
•
•
Hyper Fast Recovery: 35nsec Maximum
High Surge Rating
Low Reverse Leakage Current
Low Junction Capacitance
Hermetically Sealed, Isolated Package
providing enhanced thermal performance
Eutectic Die Attach
TX, TXV, and S Level Screening iaw MIL-
PRF-19500 Available
Maximum Ratings
Peak Repetitive Reverse Voltage
Average Rectified Forward Current
(Resistive Load, 60 Hz Sine Wave, T
C
= 100 °C)
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
A
= 25 °C)
Operating & Storage Temperature
Maximum Total Thermal Resistance
Junction to Case
TO-254 (M)
TO-254Z (Z)
SDR3004HF
SDR3005HF
SDR3006HF
Symbol
V
RRM
Io
I
FSM
T
OP
& T
STG
R
θJC
Value
400
500
600
30
500
-65 to +200
1.2
(0.9 typ)
Units
Volts
Amps
Amps
ºC
ºC/W
Total
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0089B
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SDR3006HF Series
Symbol
I
F
= 15A
I
F
= 30 A
T
A
= -55 ºC
T
A
= 100 ºC
T
A
= 25 ºC
T
A
= 100 ºC
V
F1
V
F2
Electrical Characteristic
Instantaneous Forward Voltage Drop
(T
A
= 25ºC, 300 – 500
μsec
Pulse)
Instantaneous Forward Voltage Drop
(I
F
= 15A, 300 – 500
μsec
Pulse)
Reverse Leakage Current
(100% of rated V
R
, 300
μs
pulse min.)
Reverse Recovery Time
(I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A, T
A
= 25ºC)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25ºC, f = 1MHz)
NOTES:
1/ For Ordering Information, Price, and Availability Contact Factory.
Min
––
––
Max
1.30
1.43
1.40
1.20
50
5000
35
80
Units
V
DC
V
DC
μA
nsec
pF
V
F3
V
F4
I
R1
I
R2
t
RR
C
J
––
––
––
––
Available Part Numbers:
SDR3004HFM, SDR3004HFZ, SDR3004HFMDB,
SDR3004HFZDB, SDR3004HFMUB, SDR3004HFZUB,
SDR3005HFM, SDR3005HFZ, SDR3005HFMDB ,
SDR3005HFZDB, SDR3005HFMUB, SDR3005HFZUB,
SDR3006HFM, SDR3006HFZ, SDR3006HFMDB,
SDR3006HFZDB, SDR3006HFMUB, SDR3006HFZUB
TO-254:
PIN ASSIGNMENT
PACKAGE
TO-254 (M)
TO-254Z (Z)
Pin 1
Cathode
Cathode
Pin 2
Anode
Anode
Pin 3
Anode
Anode
TO-254Z:
PIN 3
PIN 2
PIN 3
PIN 1
PIN 2
PIN 1
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0089B
DOC
