LH28F800SGE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > storage> storage> LH28F800SGE

LH28F800SGE: DescriptionFlash, 512KX16, 100ns, PDSO48, 12 X 20 MM, 1.20 MM HEIGHT, TSOP-48; Categorystorage storage; File Size2MB，48 Pages; ManufacturerSHARP; Websitehttp://sharp-world.com/products/device/

Download Datasheet Parametric Compare View All

LH28F800SGE Overview

Flash, 512KX16, 100ns, PDSO48, 12 X 20 MM, 1.20 MM HEIGHT, TSOP-48

LH28F800SGE Parametric

Parameter Name	Attribute value
Maker	SHARP
package instruction	12 X 20 MM, 1.20 MM HEIGHT, TSOP-48
Reach Compliance Code	unknown
Maximum access time	100 ns
Other features	CAN ALSO OPERATE AT 4.5 TO 5.5 SUPPLY
JESD-30 code	R-PDSO-G48
JESD-609 code	e6
length	18.4 mm
memory density	8388608 bit
Memory IC Type	FLASH
memory width	16
Number of functions	1
Number of terminals	48
word count	524288 words
character code	512000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	512KX16
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP1
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Programming voltage	3 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	2.7 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN BISMUTH
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
type	NOR TYPE
width	12 mm

Preview

Download Datasheet

View All

LH28F800SGE Related Products

	LH28F800SGE	LH28F800SGB	LH28F800SGN	LH28F800SGR
Description	Flash, 512KX16, 100ns, PDSO48, 12 X 20 MM, 1.20 MM HEIGHT, TSOP-48	Flash, 512KX16, 100ns, PBGA48, 8 X 8 MM, 0.80 MM PITCH, CSP-48	Flash, 512KX16, 100ns, PDSO44, 28.20 X 16 MM, PLASTIC, SOP-44	Flash, 512KX16, 100ns, PDSO48, 12 X 20 MM, 1.20 MM HEIGHT, REVERSE, TSOP-48
Maker	SHARP	SHARP	SHARP	SHARP
package instruction	12 X 20 MM, 1.20 MM HEIGHT, TSOP-48	8 X 8 MM, 0.80 MM PITCH, CSP-48	28.20 X 16 MM, PLASTIC, SOP-44	12 X 20 MM, 1.20 MM HEIGHT, REVERSE, TSOP-48
Reach Compliance Code	unknown	unknown	unknown	unknown
Maximum access time	100 ns	100 ns	100 ns	100 ns
Other features	CAN ALSO OPERATE AT 4.5 TO 5.5 SUPPLY	CAN ALSO OPERATE AT 4.5 TO 5.5 SUPPLY	CAN ALSO OPERATE AT 4.5 TO 5.5 SUPPLY	CAN ALSO OPERATE AT 4.5 TO 5.5 SUPPLY
JESD-30 code	R-PDSO-G48	S-PBGA-B48	R-PDSO-G44	R-PDSO-G48
length	18.4 mm	8 mm	28.2 mm	18.4 mm
memory density	8388608 bit	8388608 bit	8388608 bit	8388608 bit
Memory IC Type	FLASH	FLASH	FLASH	FLASH
memory width	16	16	16	16
Number of functions	1	1	1	1
Number of terminals	48	48	44	48
word count	524288 words	524288 words	524288 words	524288 words
character code	512000	512000	512000	512000
Operating mode	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS	ASYNCHRONOUS
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C
organize	512KX16	512KX16	512KX16	512KX16
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSOP1	TFBGA	SOP	TSOP1-R
Package shape	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE	GRID ARRAY, THIN PROFILE, FINE PITCH	SMALL OUTLINE	SMALL OUTLINE, THIN PROFILE
Parallel/Serial	PARALLEL	PARALLEL	PARALLEL	PARALLEL
Programming voltage	3 V	3 V	3 V	3 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	1.2 mm	3.15 mm	1.2 mm
Maximum supply voltage (Vsup)	3.6 V	3.6 V	3.6 V	3.6 V
Minimum supply voltage (Vsup)	2.7 V	2.7 V	2.7 V	2.7 V
surface mount	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	GULL WING	BALL	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.8 mm	1.27 mm	0.5 mm
Terminal location	DUAL	BOTTOM	DUAL	DUAL
type	NOR TYPE	NOR TYPE	NOR TYPE	NOR TYPE
width	12 mm	8 mm	13.2 mm	12 mm
JESD-609 code	e6	-	e6	e6
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Terminal surface	TIN BISMUTH	-	TIN BISMUTH	TIN BISMUTH
Maximum time at peak reflow temperature	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
