CORCOM Product Guide
High Performance RFI Filters for Switching Power Supplies
G Series
UL Recognized
CSA Certified
VDE Approved
10EG1/10VG1
6EG1/6VG1
G Series
The G series RFI filters are designed to provide excellent
common-mode and differential-mode attenuation for most
digital electronic equipment (particularly switching power
supplies) over the frequency range of 20kHz to 30MHz.
These filters are a size- and cost-effective solution for
equipment that must meet the conducted emission limits of
EN55022 Level A requirements, as well as FCC Part 15J,
Class B.
The EG models also meet the very low leakage current
requirements for VDE portable equipment as well as (120
volt) UL 544 non-patient medical equipment.
Specifications
Maximum leakage current,each line-to-ground
EG Models
@ 120 VAC 60 Hz:
.30 mA
@ 250 VAC 50 Hz:
.50 mA
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Rated current:
6EG1/6VG1
10EG1/10VG1
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Rating .01 .05 .07
EG1
06A
6 19 23
8 10 15
10A
VG1
06A
4 18 21
10A
5 10 24
Frequency-MHz
.1 .15 .5
1
25
18
25
37
29
42
30
50
48
64
56
72
44
65
55
70
5
43
65
53
70
VG Models
1.2 mA
2.0 mA
2250 VDC
1450 VDC
50/60 Hz
250 VAC
6A
10A
Electrical Schematics
6EG & 6VG Models
LINE
LOAD
10 30
40 40
60 60
45 45
60 60
Line-to-line in 50 ohm circuit
10EG & 10VG Models
LINE
LOAD
Current
Rating .01 .05 .07
EG1
06A
4
6 10
10A
5
5
5
VG1
4
7
7
06A
10A
5
5
7
Frequency-MHz
1
.1 .15 .5
24
26
26
26
37
40
39
39
66
65
67
65
75
65
75
60
5
72
60
68
60
10 30
50 50
70 70
55 55
70 70
Resistor location for reference only.
64
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
High Performance RFI Filters for Switching Power Supplies
(Continued)
G Series
RFI Power Line Filters
Case Style
EG1 & VG1
Case Dimensions
Part No.
6EG1/VG1
A
(max)
B
(max)
2.15
54.6
2.27
57.7
C
(max)
1.56
39.6
1.8
45.7
D
± .015
± .38
E
(max)
3.38
85.8
4.47
113.5
B
3.56
90.4
10EG1/VG1
4.69
119.1
2.938
74.63
4.063
103.2
D
E
A
C
Typical dimensions:
Terminals: .250 [6.35] (5) Holes: .07 [1.8] Dia.(4) Slot: .07 x .16 [1.8
x 4.1]
Mounting holes: .188 [4.78] Dia. (2)
Part Numbers
06EG1
10EG1
06VG1
10VG1
65
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
