REVISION C
DO NOT
SCALE FROM
THIS PRINT
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
C
FS5-XX-XX.X-X-DV-XX-X-TR
POSITION 1
INDICATOR
0.65 .026
REF
No OF POSITIONS
-15, -30, *-35, *-50
(PER ROW)
LEAD STYLE
-04.0: 4MM
PLATING SPECIFICATION
-L: LIGHT SELECTIVE, 10 AU / 50
NI MIN ON CONTACT, MATTE
TIN ON TAIL
ROW SPECIFICATION
-DV: DOUBLE VERTICAL
PACKAGING
-TR: TAPE & REEL
(SEE NOTES 3,4 & 5)
OPTION
-K: POLYIMIDE PAD
(SEE FIG 3, SHT 3)
WELD TAB
-TH: THRU HOLE
(USE WT-62-XX.X-TH-X)
*-SM: SURFACE MOUNT
(USE WT-62-XX.X-SM-X)
(* = NOT TOOLED)
"C" EQ. SPCS @ 0.50 .020 = "D"
0.50 .020 (TYP)
C
"A"
01
29
C
1.50 .059
X 45 REF
1.550 .061
REF
9.40 .370
REF
C
L
2.350 .093
REF
30
C
C
L
"B" REF
"A" REF
"A"
02
FS5-XX-XX.X-DV-X
WT-62-XX.X-TH-X
FS5-XX-XX.X-X
C
L
4.40 .173
REF
1.27 .050
REF
0.12 .005 (TYP) REF
0.45 .018 REF
"B"
"G"
- 0.20
+0.13
1.40 .055
C
C
"B"
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. PUSH OUT FORCE 2.22N [.50LBS].
3. TAPE & REEL WILL BE SUPPLIED WHETHER OR NOT -TR IS SPECIFIED.
4. FOR QUANTITIES UP TO 49 PCS., NO LEADER, TRAILER
OR EIA-481 REEL WILL BE SUPPLIED.
5. FOR QUANTITIES OF 50 TO 124 PCS., NO LEADER, TRAILER
OR EIA-481 REEL WILL BE SUPPLIED.
FS5-15-04.0-X-DV-TH-X-TR SHOWN
FIG 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN
MILLIMETERS[INCHES].
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
TOLERANCES ARE:
DECIMALS
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
MATERIAL:
INSULATOR: LCP, COLOR: BLACK UL 94 VO
CONTACT: BeCu
WT: PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 6:1
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
FS5 SOCKET FLOATING ASSEMBLY
F:\DWG\MISC\MKTG\FS5-XX-XX.X-X-DV-XX-X-TR-MKT.SLDDRW
BY:
R MUSSER
FS5-XX-XX.X-X-DV-XX-X-TR
08/04/2009
SHEET
1
OF
3
REVISION C
"E" REF
1.09 .043 REF
C
L
1.32 .052
REF
1.32 .052
REF
C
L
1.60 .063
REF
C-304-XX.X-X
1.00±0.07 .039±.003
C
0.56 .022 REF
0.50 .020 (TYP)
C
"F"
C
2.42 .095
REF
2.20 .087
3.45 .136 REF
C
C
SECTION "B"-"B"
0.10 [.004]
C
L
(MEASURE ALL
4 SIGNAL PIN
LOCATIONS)
0.30 .012 REF
6.65 .262 REF
C
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
9.40 .370
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
SECTION "A"-"A"
SCALE 10 : 1
F:\DWG\MISC\MKTG\FS5-XX-XX.X-X-DV-XX-X-TR-MKT.SLDDRW
DO NOT SCALE DRAWING
SHEET SCALE: 6:1
FS5 SOCKET FLOATING ASSEMBLY
BY:
R MUSSER
FS5-XX-XX.X-X-DV-XX-X-TR
08/04/2009
SHEET
2
OF
3
REVISION C
C
L
WT-62-XX.X-SM-X
C
0.10 [.004]
C
L
1.10 .043 REF
"G"
C
(APPLIES TO WT'S
AND SIGNAL PINS)
-SM WELD TAB
(FS5-15-04.0-X-DV-SM-X-TR SHOWN)
(SAME AS FIG 1, EXCEPT AS SHOWN)
(NOT TOOLED)
C
FIG 2
9.79 .386 REF
C
C
8.25 .325
"H"±0.50[.020]
0.58±0.50 .023±.020
9.40 .370
REF
C
L
C
L
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
C
L
"A" REF
-K: POLYIMIDE PAD
(USE K-DOT-.325-.450-.005)
(FS5-15-04.0-X-DV-TH-K-TR SHOWN)
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
fromparent+e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
FIG 3
4.53 .178
C
DO NOT SCALE DRAWING
SHEET SCALE: 6:1
FS5 SOCKET FLOATING ASSEMBLY
F:\DWG\MISC\MKTG\FS5-XX-XX.X-X-DV-XX-X-TR-MKT.SLDDRW
BY:
R MUSSER
FS5-XX-XX.X-X-DV-XX-X-TR
08/04/2009
SHEET
3
OF
3
