CORCOM Product Guide
Enhanced Performance Snap-In Compact RFI Filter IEC Connector Package
EJS Series
UL Recognized
CSA Certified
VDE Approved*
20EJS1
EJS1 (1-15A)
EJS Series
The new EJS series is the next generation of power inlet
filters. The 1-15 amp versions are snap-in mounted and
mechanically equivalent to the EAS/EBS series. The
performance has been enhanced to better meet the needs
for more attenuation. The EJS series also has an extended
metal flange around the socket for improved high
frequency EMI shielding as well as a larger contact area
for the panel ground.
The EJS series also includes a 20 amp version that uses
the inlet IEC 320/C20. This product was designed to keep
up with the demand for higher current equipment.
Applications include higher current power supplies and
computing equipment, which consist of work stations, base
stations, servers, etc.
*15EJS - VDE rated at 10 amps, 250 VAC
20EJS - VDE rated at 16 amps, 250 VAC
Specifications
Maximum leakage current,each line-to-ground
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Rating
01A
03A
06A
10A
15A
20A
Current
Rating
01A
03A
06A
10A
15A
20A
.01
15
-
-
-
-
-
.05
27
10
1
1
-
-
Frequency-MHz
.1 .15 .5
1
32 37 44
52
15 20 30
39
5
9 21
28
4
7 14
18
-
2
5
8
3
5 14
21
Frequency-MHz
.1 .15 .5
1
5
8 19
27
5
8 17
20
5
8 17
21
5
8 17
21
5
8 17
23
5
2 17
25
5
50
48
41
31
21
30
.22mA
.38mA
1500 VAC
1450 VDC
50/60 Hz
250 VAC
10
50
50
44
36
26
33
30
50
60
54
51
40
42
Electrical Schematic
LINE
LOAD
Line-to-line in 50 ohm circuit
.01
-
-
-
-
-
-
.05
-
-
-
-
-
-
5
45
39
32
23
33
27
10
43
42
40
36
30
35
30
9
11
16
16
11
48
Resistor location for reference only.
50
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Enhanced Performance Snap-In Compact RFI Filter IEC Connector Package
(Continued)
EJS Series
RFI Power Line Filters
Case Styles
EJS1
(1-15 amp versions)
C
D
E
B
A
Case Dimensions
Part No.
A
(max)
B
C
(max) (max)
D
± .015
± .38
E
(max)
F
(ref)
EJS8
(1-15 amp versions)
E
A
1EJS1, 3EJS1
2.20 1.10
6EJS1, 10EJS1
55.88 27.94
15EJS1
1EJS8, 3EJS8
1.54 1.10
6EJS8, 10EJS8
39.12 27.94
15EJS8
3.13 1.35
20EJS1
79.38 34.29
2.63 1.35
20EJS8
66.80 34.29
0.96 1.19 1.35
24.38 30.10 34.21
0.96 1.19 1.41
24.30 30.10 35.81
—
—
1.18 1.46 1.42
—
29.99 37.08 36.07
1.18 1.46
.624
—
29.97 37.08
15.85
Part Numbers
C
D
B
20EJS1
D
A
B
1EJS1
1EJS8
3EJS1
3EJS8
6EJS1
6EJS8
Line Cord No. (1-15A)
Insulating Boot (1-15A)
*UL, CSA — 20 Amp; VDE — 16 Amp
10EJS1
10EJS8
15EJS1
15EJS8
20EJS1*
20EJS8*
GA400
FA601
Recommended Panel Cutouts
1 to 15A EJS - all terminal types
F
C
A±.002
[.05]
E
R. 0.188 [4.78]
4X
0.815±.002
20.70±.05
Panel Cutout (front mount)
20EJS8
4.0
Min.
101.6
Panel Thickness
0.031 - 0.052 [.79
- 1.32]
0.046 - 0.068 [1.17
- 1.73]
A Dim.±.002
1.260 [32.00]
1.350 [34.29]
20EJS
C
1.417
35.99
D
F
R 0.118 Max.
3.0
1.043
26.49
A
BLUE (NEUT)
GRN/YEL
Panel Cutout (front mount)
BROWN (LINE)
B
Tolerance ±.005 [0.13]
Panel Thickness: 0.031 to 0.047 [.79-1.19]
51
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
