CORCOM Product Guide
PC Board Mountable RFI Power Line Filters for Emission Control Applications
X, Y, Z Series
XP/YP/ZP
UL Recognized
CSA Certified
VDE Approved
Specifications
X, Y, Z Series
X, Y, and Z series RFI filters are compact, PC board
mountable components, designed to consume minimal
board space. They provide a choice of three levels of
performance, intended to be all the power line filter needed
for the corresponding emission control application.
X Series
– designed to bring most digital equipment
(including switching power supplies) into compliance with
FCC Part 15J, Class B conducted emission limits.
Y Series
– designed to bring most digital equipment
(including switching power supplies) into compliance with
EN55022, Level A, and FCC Part 15J, Class B conducted
emission limits.
Z Series
– designed to bring most digital equipment
(including switching power supplies) into compliance with
EN55022, Level B (as well as FCC Part 15J, Class B)
conducted emission limits.
This high compliance confidence level is attained by
optimizing the differential mode performance of each series
for the frequency range it needs to cover in the
corresponding application. At the same time, excellent
common mode performance is maintained across the
frequency range of 10kHz to 30MHz, while still meeting the
very low leakage current requirements of SEV and VDE
portable equipment.
Maximum leakage current,each line-to-ground
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Rated current:
1EZP
60˚C
2EYP/2EZP
60˚C
3EXP
60˚C
3EYP
55˚C
3EZP
50˚C
4EXP/4EYP
55˚C
6EXP
55˚C
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Frequency–MHz
Rating
.01 .05 .15 .5
1
5
EX
3A
2
13 21 35 46 44
4A
2
13 22 38 44 44
6A
2
11 20 35 40 40
EY
2A
8
21 31 49 44 40
3A
11 24 36 43 40 40
4A
5
18 28 45 40 40
EZ
1A
18 32 43 47 44 43
2A
18 32 45 41 40 40
3A
15 29 39 43 42 40
Line-to-line in 50 ohm circuit
Current
Frequency–MHz
.02 .03 .05 .07 .15 .5 1
Rating
EX
3A
4A
6A
EY
2A
3A
4A
EZ
1A
2A
3A
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
3EX1/3EZ1
.30 mA
.50 mA
2250 VDC
1450 VDC
50/60 Hz
250 VAC
1A
2A
3A
3A
3A
4A
6A
10
44
44
40
40
40
40
43
40
40
30
44
38
36
40
40
36
45
40
40
Electrical Schematic
LINE
LOAD
5
60
70
70
70
67
70
70
65
70
10 30
45 50
65 55
60 55
60 55
62 50
65 55
60 55
55 50
60 55
Resistor location for reference only.
-
-
-
-
-
-
7
2
-
-
-
-
-
-
-
29
15
10
-
-
-
10
10
6
34
31
26
5 34 60 65
10 37 70 70
3 31 65 70
19 40 70 75
20 42 68 68
18 41 67 75
43 62 70 70
40 57 75 70
34 53 75 75
100
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
PC Board Mountable RFI Power Line Filters for Emission Control Applications
(Continued)
X, Y, Z Series
RFI Power Line Filters
Case Styles
EX1/EZ1
Case Dimensions
Part No.
A
(max)
2.61
66.3
3.01
76.7
2.61
66.3
2.61
66.3
2.61
66.3
2.61
66.3
2.61
66.3
2.61
66.3
3.54
89.9
B
(max)
1.13
28.7
1.84
46.8
1.13
28.7
1.13
28.7
1.13
28.7
1.13
28.7
1.13
28.7
1.13
28.7
2.08
52.8
C
(max)
1.62
41.1
1.16
29.46
1.62
41.1
1.75
44.5
1.62
41.1
1.75
44.5
1.62
41.1
1.75
44.5
1.31
33.3
D
± .015
± .38
E
(max)
—
2.79
70.87
—
—
—
—
—
—
3.35
85.1
B
D
E
A
Typical dimensions:
Terminals: .250 [6.35] (5)
Slot: .07 x .16 [1.8
x 4.1]
3EXP
3EX1
4EXP
6EXP
—
2.375
60.33
—
—
—
—
—
—
2.938
74.63
C
Holes: .07 [1.8] Dia.(4)
Mounting holes: .188 [4.78] Dia. (2)
2EYP
3EYP, 4EYP
EXP/EYP/EZP
A
1EZP
2EZP, 3EZP
C
3EZ1
0.123
Min.
3.12
Grounds
Part Numbers
Load
side
B
Line
side
Recommended Mounting Holes & Clearance Area
.605
15.37
2.660
67.56
1.050
26.67
1.850
46.99
3EXP
3EX1
4EXP
6EXP
2EYP
3EYP
4EYP
1EZP
2EZP
3EZP
3EZ1
1.190 .700
30.23 17.78
.245
6.22
.350
8.89
.150
3.81
Tolerance ± .006 [.152]
Holes: .075 [1.91] Dia. (6)
101
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
