SK510-LTP: Description5 A, 100 V, SILICON, RECTIFIER DIODE, DO-214AB, SMCJ, 2 PIN; CategoryDiscrete semiconductor diode; File Size230KB，4 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

SK510-LTP Overview

5 A, 100 V, SILICON, RECTIFIER DIODE, DO-214AB, SMCJ, 2 PIN

SK510-LTP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Parts packaging code	DO-214AB
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	compliant
application	GENERAL PURPOSE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	DO-214AB
JESD-30 code	R-PDSO-C2
JESD-609 code	e3
Humidity sensitivity level	NOT SPECIFIED
Maximum non-repetitive peak forward current	100 A
Number of components	1
Phase	1
Number of terminals	2
Maximum output current	5 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	100 V
surface mount	YES
technology	SCHOTTKY
Terminal surface	MATTE TIN
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	10

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

SK52L

THRU

SK510L

5 Amp Schottky

Rectifier

20 to 100 Volts

DO-214AB

(SMC) (LEAD FRAME)

Features

•

Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates

Compliant. See ordering information)

High Current Capability

For Surface Mount Applications

Higher Temp Soldering : 260

°C

for 10 Seconds At Terminals

Available on Tape and Reel

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0and

MSL rating 1

•

Maximum Ratings

•

Operating Temperature: -55

C to +150

Storage Temperature: -55

C to +150

Maximum Thermal Resistance; 16

C/W Junction To Lead

55°C/W Junction To Ambient

MCC

Catalog

Number

SK52L

SK53L

SK54L

SK55L

SK56L

SK58L

SK510L

Device

Marking

SK52

SK53

SK54

SK55

SK56

SK58

SK510

Maximum

Reccurrent

Peak Reverse

Voltage

20V

30V

40V

50V

60V

80V

100V

Maximum

RMS

Voltage

14V

21V

28V

35V

42V

56V

70V

Maximum

Blocking

Voltage

20V

30V

40V

50V

60V

80V

100V

Electrical Characteristics @ 25°C Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum

Instantaneous

Forward Voltage

SK52L~54L

SK55L~56L

SK58L~510L

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Typical Junction

Capacitance

Note:

DIMENSIONS

INCHES

MIN

.260

.220

.006

.030

.305

.079

.108

.002

MIN

6.60

5.59

0.15

0.76

7.75

2.00

2.75

0.050

F(AV)

FSM

5.0A

100A

= 120°C

8.3ms, half sine

DIM

MAX

.280

.245

.012

.060

.320

.103

.128

.008

MAX

7.11

6.22

0.31

..52

8.13

2.62

3.25

0.203

NOTE

.55V

.75V

.85V

1.0mA

20mA

200pF

= 5.0A;

= 25°C

SUGGESTED SOLDER

PAD LAYOUT

0.190

= 25°C

= 100°C

Measured at

1.0MHz, V

=4.0V

0.125”

0.070”

*Pulse test: Pulse width 200

µsec,

Duty cycle 2%

High Temperature Solder Exemptions Applied, see EU Directive Annex 7.

Revision:

www.mccsemi.com

1 of 4

2010/11/02
