HD66712A01T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> HD66712A01T

HD66712A01T: DescriptionDot Matrix LCD Driver, 34 X 60 Dots, MOS; CategoryThe embedded processor and controller Microcontrollers and processors; File Size52KB，1 Pages; ManufacturerHitachi （Renesas ）; Websitehttp://www.renesas.com/eng/

Download Datasheet Parametric Compare View All

HD66712A01T Overview

Dot Matrix LCD Driver, 34 X 60 Dots, MOS

HD66712A01T Parametric

Parameter Name	Attribute value
Maker	Hitachi （Renesas ）
package instruction	DIE,
Reach Compliance Code	unknown
Address bus width	1
Bus compatibility	HD6800; HMCS4019R
maximum clock frequency	2 MHz
show configuration	34 X 60 DOTS
External data bus width	8
JESD-30 code	R-XUUC-N128
Number of terminals	128
Maximum operating temperature	75 °C
Minimum operating temperature	-20 °C
Package body material	UNSPECIFIED
encapsulated code	DIE
Package shape	RECTANGULAR
Package form	UNCASED CHIP
Certification status	Not Qualified
Maximum supply voltage	5.5 V
Minimum supply voltage	2.7 V
Nominal supply voltage	5 V
surface mount	YES
technology	MOS
Temperature level	COMMERCIAL EXTENDED
Terminal form	NO LEAD
Terminal location	UPPER
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER

Preview

Download Datasheet

View All

HD66712A01T Related Products

	HD66712A01T	HD66712A02T	HD66710XXXFS	HD66712A01	HD66712A01F	HD66712A02	HD66712A02F	HD66712A00
Description	Dot Matrix LCD Driver, 34 X 60 Dots, MOS	Dot Matrix LCD Driver, 34 X 60 Dots, MOS	Dot Matrix LCD Driver, 33 X 40 Dots, MOS, PQFP100	Dot Matrix LCD Driver, 34 X 60 Dots, MOS	Dot Matrix LCD Driver, 34 X 60 Dots, MOS, PQFP128	Dot Matrix LCD Driver, 34 X 60 Dots, MOS	Dot Matrix LCD Driver, 34 X 60 Dots, MOS, PQFP128	Dot Matrix LCD Driver, 34 X 60 Dots, MOS
package instruction	DIE,	DIE,	QFP,	DIE,	QFP,	DIE,	QFP,	DIE,
Reach Compliance Code	unknown	unknow	unknown	unknown	unknown	unknown	unknown	unknown
Address bus width	1	1	1	1	1	1	1	1
Bus compatibility	HD6800; HMCS4019R	HD6800; HMCS4019R	HD6800; HD6301	HD6800; HMCS4019R	HD6800; HMCS4019R	HD6800; HMCS4019R	HD6800; HMCS4019R	HD6800; HMCS4019R
maximum clock frequency	2 MHz	2 MHz	2 MHz	2 MHz	2 MHz	2 MHz	2 MHz	2 MHz
show configuration	34 X 60 DOTS	34 X 60 DOTS	33 X 40 DOTS	34 X 60 DOTS	34 X 60 DOTS	34 X 60 DOTS	34 X 60 DOTS	34 X 60 DOTS
External data bus width	8	8	8	8	8	8	8	8
JESD-30 code	R-XUUC-N128	R-XUUC-N128	R-PQFP-G100	X-XUUC-N100	R-PQFP-G128	X-XUUC-N100	R-PQFP-G128	X-XUUC-N100
Number of terminals	128	128	100	100	128	100	128	100
Package body material	UNSPECIFIED	UNSPECIFIED	PLASTIC/EPOXY	UNSPECIFIED	PLASTIC/EPOXY	UNSPECIFIED	PLASTIC/EPOXY	UNSPECIFIED
encapsulated code	DIE	DIE	QFP	DIE	QFP	DIE	QFP	DIE
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	UNSPECIFIED	RECTANGULAR	UNSPECIFIED	RECTANGULAR	UNSPECIFIED
Package form	UNCASED CHIP	UNCASED CHIP	FLATPACK	UNCASED CHIP	FLATPACK	UNCASED CHIP	FLATPACK	UNCASED CHIP
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
technology	MOS	MOS	MOS	MOS	MOS	MOS	MOS	MOS
Terminal form	NO LEAD	NO LEAD	GULL WING	NO LEAD	GULL WING	NO LEAD	GULL WING	NO LEAD
Terminal location	UPPER	UPPER	QUAD	UPPER	QUAD	UPPER	QUAD	UPPER
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER
Maker	Hitachi （Renesas ）	-	Hitachi （Renesas ）	Hitachi （Renesas ）	Hitachi （Renesas ）	Hitachi （Renesas ）	Hitachi （Renesas ）	-
Maximum operating temperature	75 °C	75 °C	75 °C	-	75 °C	-	75 °C	-
Minimum operating temperature	-20 °C	-20 °C	-20 °C	-	-20 °C	-	-20 °C	-
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	-	COMMERCIAL EXTENDED	-	COMMERCIAL EXTENDED	-
