CTLH1608F Series
From 1.0 nH to 220 nH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLH1608F-3N3_
S = ±0.3nH, J = ±5%, K = ±10%
* S, K only
** J, K only
Inductance
at 100MHz
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
62
68
82
Q Min. at
(MHz)
50
100
8
8
8
8
8
10
10
10
10
10
10
10
12
12
12
12
12
12
12
12
12
12
12
12
12
12
8
8
8
8
Q Typ. at
(MHz)
50 100 300 500 800
12
13
13
13
13
13
13
13
13
13
13
13
13
15
15
15
17
17
18
18
18
18
18
18
18
18
14
15
15
15
20
16
16
16
43
44
45
46
46
46
47
47
41
41
44
44
45
46
48
48
45
43
39
37
35
32
32
32
30
20
SRF
Typ.
(MHz)
10000
10000
8000
8000
7200
6200
5200
5000
4750
4100
3750
3300
3000
2600
2500
2400
2000
1900
1600
1400
1300
1100
1050
1050
900
770
850
550
520
500
DCR
Max
Ω
(Ω)
.10
.10
.10
.10
.10
.10
.12
.14
.16
.18
.22
.24
.26
.28
.32
.35
.40
.45
.55
.60
.70
.75
.85
.85
1.0
1.2
2.3
2.4
2.7
3.0
IDC
Max.
)
(mA)
500
500
500
500
500
500
500
500
500
500
500
500
300
300
300
300
300
300
300
300
300
300
300
300
300
300
250
250
250
250
Compliant
RoHS
CTLH1608F-1N0S
CTLH1608F-1N2S
CTLH1608F-1N5S
CTLH1608F-1N8S
CTLH1608F-2N2S
CTLH1608F-2N7S
CTLH1608F-3N3_*
CTLH1608F-3N9_*
CTLH1608F-4N7_*
CTLH1608F-5N6_*
CTLH1608F-6N8_**
CTLH1608F-8N2_**
CTLH1608F-10N_**
CTLH1608F-12N_**
CTLH1608F-15N_**
CTLH1608F-18N_**
CTLH1608F-22N_**
CTLH1608F-27N_**
CTLH1608F-33N_**
CTLH1608F-39N_**
CTLH1608F-47N_**
CTLH1608F-56N_**
CTLH1608F-62N_**
CTLH1608F-68N_**
CTLH1608F-82N_**
CHARACTERISTICS
Description:
Ceramic core, multi-layer chip inductor for high
frequency applications
Applications:
RF Resonance and Impedance Matching Circuit.
RF and wireless communicaton. Information technology
equipment, computers, telecommunications, radar detectors,
automotive electronics, cellular phones, pagers, PDAs, keyless
remote systems. Use in L-C filter configurations.
Operating Temperature:
-40°C to +100°C
Inductance Tolerance:
±0.3nH, ±5%, ±10%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTLH1608F-R10_**
100
CTLH1608F-R12_**
*120
CTLH1608F-R15_**
*150
CTLH1608F-R18_**
*180
CTLH1608F-R22_**
*220
*Inductance Test Freq. at 50MHz
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.6±0.15
0.06±0.006
B
0.8±0.15
0.03±0.006
C
0.8±0.15
0.03±0.006
D
0.3±0.2
0.01±0.008
PAD LAYOUT
Unit: mm(inch)
2.4~3.4
(0.09~0.13)
Polarity
Mark
0.6
(0.02)
Top View
0.8
(0.03)
05.15.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
