PCF2113AU/10 datasheet, PDF - EEWORLD Datasheet

PCF2113AU/10: DescriptionIC 18 X 60 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC100, Display Controller; CategoryThe embedded processor and controller Microcontrollers and processors; File Size13KB，1 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

PCF2113AU/10 Overview

IC 18 X 60 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC100, Display Controller

Parameter Name	Attribute value
Maker	NXP
package instruction	DIE,
Contacts	100
Reach Compliance Code	unknown
Address bus width	1
Bus compatibility	I2C
maximum clock frequency	2 MHz
show configuration	18 X 60 DOTS
External data bus width	8
JESD-30 code	X-XUUC-N100
Number of terminals	100
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	UNSPECIFIED
encapsulated code	DIE
Package shape	UNSPECIFIED
Package form	UNCASED CHIP
Certification status	Not Qualified
Maximum slew rate	0.4 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	1.8 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	NO LEAD
Terminal location	UPPER
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER

	PCF2113AU/10	PCF2113AU/F2	PCF2113DU/10
Description	IC 18 X 60 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC100, Display Controller	IC 18 X 60 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC100, Display Controller	IC 18 X 60 DOTS DOT MAT LCD DRVR AND DSPL CTLR, UUC100, Display Controller
Maker	NXP	NXP	NXP
package instruction	DIE,	DIE,	DIE,
Reach Compliance Code	unknown	unknown	unknown
Address bus width	1	1	1
Bus compatibility	I2C	I2C	I2C
maximum clock frequency	2 MHz	2 MHz	2 MHz
show configuration	18 X 60 DOTS	18 X 60 DOTS	18 X 60 DOTS
External data bus width	8	8	8
JESD-30 code	X-XUUC-N100	X-XUUC-N100	X-XUUC-N100
Number of terminals	100	100	100
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
encapsulated code	DIE	DIE	DIE
Package shape	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package form	UNCASED CHIP	UNCASED CHIP	UNCASED CHIP
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	0.4 mA	0.4 mA	0.4 mA
Maximum supply voltage	5.5 V	5.5 V	5.5 V
Minimum supply voltage	1.8 V	1.8 V	1.8 V
Nominal supply voltage	5 V	5 V	5 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	NO LEAD	NO LEAD	NO LEAD
Terminal location	UPPER	UPPER	UPPER
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER	DISPLAY CONTROLLER, DOT MATRIX LCD DRIVER
