SAMSUNG ELECTRONICS RESERVES THE RIGHT TO CHANGE PRODUCTS, INFORMATION AND
SPECIFICATIONS WITHOUT NOTICE.
Products and specifications discussed herein are for reference purposes only. All information discussed
herein is provided on an "AS IS" basis, without warranties of any kind.
This document and all information discussed herein remain the sole and exclusive property of Samsung
Electronics. No license of any patent, copyright, mask work, trademark or any other intellectual property
right is granted by one party to the other party under this document, by implication, estoppel or other-
wise.
Samsung products are not intended for use in life support, critical care, medical, safety equipment, or
similar applications where product failure could result in loss of life or personal or physical harm, or any
military or defense application, or any governmental procurement to which special terms or provisions
may apply.
For updates or additional information about Samsung products, contact your nearest Samsung office.
All brand names, trademarks and registered trademarks belong to their respective owners.
ⓒ
2010 Samsung Electronics Co., Ltd. All rights reserved.
-1-
K4T1G044QE
K4T1G084QE
K4T1G164QE
datasheet
History
- Initial Release
- Corrected Typo.
- Updated AC/DC operating condition with the JEDEC updated
(JESD79-2E)
- Changed layout
Draft Date
Aug. 2008
Sep. 2008
Dec. 2008
Feb. 2010
Rev. 1.11
DDR2 SDRAM
Revision History
Revision No.
1.0
1.01
1.1
1.11
Remark
-
-
-
-
Editor
S.H.Kim
S.H.Kim
S.H.Kim
S.H.Kim
-2-
K4T1G044QE
K4T1G084QE
K4T1G164QE
datasheet
Rev. 1.11
DDR2 SDRAM
Table Of Contents
1Gb E-die DDR2 SDRAM
1. Ordering Information ..................................................................................................................................................... 4
6. Absolute Maximum Ratings .......................................................................................................................................... 12
7. AC & DC Operating Conditions..................................................................................................................................... 12
7.1 Recommended DC operating Conditions (SSTL_1.8)............................................................................................. 12
7.2 Operating Temperature Condition ........................................................................................................................... 13
7.3 Input DC Logic Level ............................................................................................................................................... 13
7.4 Input AC Logic Level ............................................................................................................................................... 13
7.5 AC Input Test Conditions......................................................................................................................................... 13
7.6 Differential input AC logic Level............................................................................................................................... 14
7.7 Differential AC output parameters ........................................................................................................................... 14
8. ODT DC electrical characteristics ................................................................................................................................. 14
10. IDD Specification Parameters and Test Conditions .................................................................................................... 16
13. Electrical Characteristics & AC Timing for DDR2-800/667 ......................................................................................... 20
13.1 Refresh Parameters by Device Density................................................................................................................. 20
13.2 Speed Bins and CL, tRCD, tRP, tRC and tRAS for Corresponding Bin ................................................................ 20
13.3 Timing Parameters by Speed Grade ..................................................................................................................... 21
14. General notes, which may apply for all AC parameters .............................................................................................. 23
15. Specific Notes for dedicated AC parameters .............................................................................................................. 25
-3-
K4T1G044QE
K4T1G084QE
K4T1G164QE
datasheet
DDR2-800 5-5-5
K4T1G044QE-HC(L)E7
K4T1G084QE-HC(L)E7
K4T1G164QE-HC(L)E7
DDR2-800 6-6-6
K4T1G044QE-HC(L)F7
K4T1G084QE-HC(L)F7
K4T1G164QE-HC(L)F7
Rev. 1.11
DDR2 SDRAM
DDR2-667 5-5-5
K4T1G044QE-HC(L)E6
K4T1G084QE-HC(L)E6
K4T1G164QE-HC(L)E6
Package
60 FBGA
60 FBGA
84 FBGA
1. Ordering Information
Organization
256Mx4
128Mx8
64Mx16
NOTE
:
1. Speed bin is in order of CL-tRCD-tRP.
2. RoHS Compliant.
3. “H” of Part number(12th digit) stands for Lead-Free, Halogen-Free, and RoHS compliant products.
4. “C” of Part number(13th digit) stands normal, and “L” stands for Low power products.
• Bi-directional Differential Data-Strobe (Single-ended data-strobe is an
optional feature)
• Off-Chip Driver(OCD) Impedance Adjustment
• On Die Termination
• Special Function Support
- 50ohm ODT
- High Temperature Self-Refresh rate enable
• Average Refresh Period 7.8us at lower than T
CASE
85°C, 3.9us at
85°C < T
CASE
< 95
°C
• All of products are Lead-Free, Halogen-Free, and RoHS compliant
The 1Gb DDR2 SDRAM is organized as a 32Mbit x 4 I/Os x 8banks, 16Mbit
x 8 I/Os x 8banks or 8Mbit x 16 I/Os x 8 banks device. This synchronous
device achieves high speed double-data-rate transfer rates of up to 800Mb/
sec/pin (DDR2-800) for general applications.
The chip is designed to comply with the following key DDR2 SDRAM fea-
tures such as posted CAS with additive latency, write latency = read latency
- 1, Off-Chip Driver(OCD) impedance adjustment and On Die Termination.
All of the control and address inputs are synchronized with a pair of exter-
nally supplied differential clocks. Inputs are latched at the crosspoint of dif-
ferential clocks (CK rising and CK falling). All I/Os are synchronized with a
pair of bidirectional strobes (DQS and DQS) in a source synchronous fash-
ion. The address bus is used to convey row, column, and bank address
information in a RAS/CAS multiplexing style. For example, 1Gb(x8) device
receive 14/10/3 addressing.
The 1Gb DDR2 device operates with a single 1.8V ± 0.1V power supply
and 1.8V ± 0.1V V
DDQ
.
The 1Gb DDR2 device is available in 60ball FBGA(x4/x8) and in 84ball
FBGA(x16).
NOTE
:
1. This data sheet is an abstract of full DDR2 specification and does not cover the common features which are described in “DDR2 SDRAM Device Operation & Timing Dia-
gram”.
2. The functionality described and the timing specifications included in this data sheet are for the DLL Enabled mode of operation.
