• Guard Ring Construction For Transient Protection
• High Conductance
Applications:
•
0.5A surface mount schottky barrier rectifier
Maximum Ratings:
T
a
= 25°C unless otherwise specified.
Characteristic
Peak repetitive reverse voltage
Working peak reverse voltage
DC reverse voltage
RMS reverse voltage
Average rectified output current at T
L
= 100°C
Non-Repetitive peak forward surge current 8.3Ms single half
sine-wave superimposed on rated load
Power dissipation
Thermal resistance junction to ambient
Operating and storage temperature range
Voltage rate of change
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
o
I
FSM
P
d
R
θJA
T
j
, T
STG
dv/dt
Value
Unit
40
V
28
0.5
5.5
410
244
-65 to+125
1,000
V
A
A
mW
°C/W
°C
V/µs
www.element14.com
www.farnell.com
www.newark.com
Page <1>
25/02/13
V1.0
Schottky Barrier Diode
Electrical Characteristics:
T
a
= 25°C unless otherwise specified.
Characteristic
Minimum reverse
Breakdown voltage
Symbol
V
(BR)R
B0540W-7-F
-
-
40
-
0.51
0.62
-
0.46
0.61
-
-
10
-
20
-
5.0
13
Junction capacitance
C
J
170
Unit
V
Test Conditions
I
R
= 250μA
I
R
= 130μA
I
R
= 20μA
I
F
=0.1A, T
j
=25°C
I
F
=0.5A, T
j
=25°C
I
F
=1.0A, T
j
=25°C
I
F
=0.1A, T
j
=100°C
I
F
=0.5A, T
j
=100°C
I
F
=1.0A, T
j
=100°C
V
R
=10V, T
j
=25°C
V
R
=15V, T
j
=25°C
V
R
=20V, T
j
=25°C
V
R
=30V, T
j
=25°C
V
R
=40V, T
j
=25°C
V
R
=10V, T
j
=100°C
V
R
=20V, T
j
=100°C
V
R
=40V, T
j
=100°C
f=1MHz, V
R
=0V DC
Maximum forward voltage drop
V
FM
V
μA
Maximum leakage current
I
RM
mA
pF
Typical Characteristics:
T
a
= 25°C unless otherwise specified.
www.element14.com
www.farnell.com
www.newark.com
Page <2>
25/02/13
V1.0
Schottky Barrier Diode
Package Outline:
Plastic surface mounted package
SOD-123
Dim.
A
B
C
D
E
H
J
K
3.55
0.5
0.3
0.02
0.1 Typ.
3.85
Min.
1.4
2.55
Max.
1.8
2.85
1.15 Typ.
0.6
0.4
0.1
Dimensions : Millimetres
Soldering Footprint:
Package Information:
Device
B0540W-7-F
Package
Shipping
SOD-123 3,000 / Tape & Reel
Dimensions : Millimetres
Part Number Table
Description
Schottky Barrier Diode
Part Number
B0540W-7-F
