Document 186-1
Shielded Power Inductors – DS1608C
These shielded inductors can help achieve significantly
longer battery life in handheld devices and other portable
products.
They offer high efficiency and small size. Their flat top and
heat resistant materials ensure trouble-free assembly and
reflow operations.
0.115
max
2,92
0.260 max
6,60
0.070
1,78
Recommended
Land Pattern
0.050
1,27
0.090
2,29
0.270
6,86
0.055
1,40
0.160
4,06
0.140
3,56
Coilcraft will continue to manufacture and support
the DS1608C indefinitely. For new designs, consider
the MSS7341, MSS1038 or LPS4018 as alternatives.
These series are more cost effective and offer better
current handling. In addition, the LPS4018 is a signifi-
cantly smaller part.
0.175 max
4,45
0.170 min
4,32
0.040
1,02
Dash
number
Part marking since Feb. 2005. Parts manufactured
prior to that date may have color dots.
Visit www.coilcraft.com/colrpowr.cfm for details.
0.115
2,92
max
0.260 max
6,60
0.070
1,78
0.175 max
4,45
Recommended
Land Pattern
0.050
1,27
0.090
2,29
0.270
6,86
0.055
1,40
0.160
4,06
0.140
3,56
Core material
Ferrite
Terminations
RoHS compliant electroplated gold (<50 µin) over nickel
over moly-manganese. Other terminations available at additional cost.
Weight
144 – 167 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
750/7″ reel; 2500/13″ reel Plastic tape: 12 mm wide,
0.28 mm thick, 4 mm pocket spacing, 3 mm pocket depth
PCB washing
Tested to MIL-STD-202 Method 215 plus an additional
aqueous wash. See
Doc787_PCB_Washing.pdf.
0.170 min
4,32
Part marking since Feb. 2005. Parts manufactured
prior to that date may have color dots.
Visit www.coilcraft.com/colrpowr.cfm for details.
XXX
0.040
1,02
Dash
number
XXX
Document 186-1
Revised 02/07/14
Document 186-2
Shielded Power Inductors – DS1608C
Part
DS1608C-102_L_
DS1608C-152_L_
DS1608C-222_L_
DS1608C-332_L_
DS1608C-472_L_
DS1608C-682_L_
DS1608C-822_L_
DS1608C-103_L_
DS1608C-153_L_
DS1608C-223_L_
DS1608C-333_L_
DS1608C-473_L_
DS1608C-683_L_
DS1608C-104_L_
DS1608C-154_L_
DS1608C-224_L_
DS1608C-334_L_
DS1608C-474_L_
DS1608C-684_L_
DS1608C-105_L_
DS1608C-155_L_
DS1608C-225_L_
DS1608C-335_L_
DS1608C-475_L_
DS1608C-685_L_
DS1608C-106_L_
number
1
Inductance
2
±20% (µH)
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10000
Percent
tolerance
3
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10
20,10,5
20,10,5
Q min
30 @ 200 kHz
30 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 200 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
40 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
50 @ 100 kHz
DCR max
(Ohms)
0.040
0.045
0.050
0.055
0.060
0.065
0.070
0.075
0.090
0.11
0.19
0.23
0.29
0.48
0.59
0.77
1.4
1.8
2.2
3.4
4.2
8.5
11.0
13.9
25.0
32.8
SRF typ
(MHz)
250
125
120
120
105
50
42
38
33
25
20
20
15
10
9
6
5
4
3
2
2
2
1
1
1
0.8
Isat
4
(A)
1.4
0.93
0.92
0.75
0.58
0.58
0.47
0.37
0.31
0.30
0.30
0.24
0.17
0.13
0.10
0.10
0.07
0.06
0.055
0.045
0.035
0.028
0.024
0.021
0.019
0.017
1. When ordering, please specify
tolerance, termination
and
packaging
codes:
DS1608C-106MLC
Tolerance: M
= 20%,
K
= 10%,
J
= 5% (Table above shows stock tolerances in bold.)
Termination: L
= RoHS compliant gold over nickel over moly-manganese
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic tape (750 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic tape (2500 parts per full reel).
2. Inductance tested at 0.1 Vrms, 100 kHz, 0 Adc.
3. Tolerances in bold are stocked for immediate shipment.
4. DC current at which the inductance drops 30% (typ.) from its value without current.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Document 186-2
Revised 02/07/14
