CAT8710LTD-GT3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> CAT8710LTD-GT3

CAT8710LTD-GT3: DescriptionQuad Voltage Supervisor; CategoryPower/power management The power supply circuit; File Size218KB，1 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

CAT8710LTD-GT3 Overview

Quad Voltage Supervisor

CAT8710LTD-GT3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ON Semiconductor
Parts packaging code	TSSOP
package instruction	VSSOP, TSOP6,.11,37
Contacts	6
Reach Compliance Code	compli
ECCN code	EAR99
Adjustable threshold	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY MANAGEMENT CIRCUIT
JESD-30 code	R-PDSO-G6
JESD-609 code	e4
length	2.9 mm
Number of channels	1
Number of functions	1
Number of terminals	6
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	VSSOP
Encapsulate equivalent code	TSOP6,.11,37
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	1.5/5.5 V
Certification status	Not Qualified
Maximum seat height	1 mm
Maximum supply current (Isup)	0.009 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	1.5 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	1.6 mm

Preview

Download Datasheet

View All

Product Overview

CAT8710: Quad Voltage Supervisor

For complete documentation, see the data sheet.

The CAT8710 is a space-saving, precision quad voltage supervisor, designed to monitor up to four supply voltages with a single

device. When any supply voltage drops below its preset threshold, the CAT8710 will output a single reset to the threshold. One

CAT8710 IC eliminates the need for multiple reset circuits, which minimizes system components and improves reliability.

The CAT8710 provides 2 factory preset thresholds for monitoring 3.3 V, 3.0 V, 2.5 V, and 1.8 V supplies within ±5% and 2 user-

selectable thresholds, adjustable down to 0.62 V with 2% accuracy. On power up, the reset remains low for 120 ms typical, after all

voltages have risen above their selected thresholds. The output remains valid as long as VDD remains above 1 V.

The CAT8710 is available in a 6-pin TSOT-23 package and operates over the industrial temperature range of -40°C to +85°C.

Features

• 2 factory preset reset threshold options for 3.3 V, 3.0 V, 2.5 V

and 1.8 V supplies

• Low supply current: 3.0 A (typ)

• Small, TSOT-23 6-pin package

• Monitors 4 power supply voltages simultaneously

• 2 user-programmed threshold monitors, adjustable down to

0.62 V with 2% accuracy

• Drop-in replacement to MAX6710

• Ultra-low power vs. Maxim

• Reset timeout period: 120 ms (typ)

• /RESET valid to V

= 1.0 V

• Immune to short supply transients

For more features, see the data sheet

Benefits

• Common power supply voltage selections pre-set at the

factory save external components and lower cost.

• Lower power consumption, typically consuming 10% of the

power required for similar competing products

• Consolidates four monitors into the space of one - uses only

25% of the board space

Applications

• Monitoring of multiple power supply voltages

For more information please contact your local sales support at www.onsemi.com.

Created on: 9/29/2018

CAT8710LTD-GT3 Related Products

	CAT8710LTD-GT3	CAT8710	CAT8710JTD-GT3	CAT8710NTD-GT3	CAT8710PTD-GT3
Description	Quad Voltage Supervisor	Quad Voltage Supervisor	Quad Voltage Supervisor	Quad Voltage Supervisor	Quad Voltage Supervisor
Is it lead-free?	Lead free	-	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	-	conform to	conform to	conform to
Maker	ON Semiconductor	-	ON Semiconductor	ON Semiconductor	ON Semiconductor
Parts packaging code	TSSOP	-	TSSOP	TSSOP	TSSOP
package instruction	VSSOP, TSOP6,.11,37	-	VSSOP, TSOP6,.11,37	VSSOP, TSOP6,.11,37	VSSOP, TSOP6,.11,37
Contacts	6	-	6	6	6
Reach Compliance Code	compli	-	compli	compli	compli
ECCN code	EAR99	-	EAR99	EAR99	EAR99
Adjustable threshold	YES	-	YES	YES	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY MANAGEMENT CIRCUIT	-	POWER SUPPLY MANAGEMENT CIRCUIT	POWER SUPPLY MANAGEMENT CIRCUIT	POWER SUPPLY MANAGEMENT CIRCUIT
JESD-30 code	R-PDSO-G6	-	R-PDSO-G6	R-PDSO-G6	R-PDSO-G6
JESD-609 code	e4	-	e4	e4	e4
length	2.9 mm	-	2.9 mm	2.9 mm	2.9 mm
Number of channels	1	-	1	1	1
Number of functions	1	-	1	1	1
Number of terminals	6	-	6	6	6
Maximum operating temperature	85 °C	-	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	VSSOP	-	VSSOP	VSSOP	VSSOP
Encapsulate equivalent code	TSOP6,.11,37	-	TSOP6,.11,37	TSOP6,.11,37	TSOP6,.11,37
Package shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	-	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
power supply	1.5/5.5 V	-	1.5/5.5 V	1.5/5.5 V	1.5/5.5 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1 mm	-	1 mm	1 mm	1 mm
Maximum supply current (Isup)	0.009 mA	-	0.009 mA	0.009 mA	0.009 mA
Maximum supply voltage (Vsup)	5.5 V	-	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	1.5 V	-	1.5 V	1.5 V	1.5 V
Nominal supply voltage (Vsup)	1.8 V	-	1.8 V	1.8 V	1.8 V
surface mount	YES	-	YES	YES	YES
Temperature level	INDUSTRIAL	-	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	NICKEL PALLADIUM GOLD	-	NICKEL PALLADIUM GOLD	NICKEL PALLADIUM GOLD	NICKEL PALLADIUM GOLD
Terminal form	GULL WING	-	GULL WING	GULL WING	GULL WING
Terminal pitch	0.95 mm	-	0.95 mm	0.95 mm	0.95 mm
Terminal location	DUAL	-	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
width	1.6 mm	-	1.6 mm	1.6 mm	1.6 mm
