Super Flux Premium Red LED
OSR5PAZ3K1D
■Features
●
■
Outline
Dimension
7.62
High Luminous Super Flux Output
Flat Standard Directivity
Long Lifetime Operation
7.62
●
●
Unit:mm
Tolerance:+0.3mm
1,4 Cathode
2,3 Anode
1.
2C
●
Low Thermal Resistance
Superior Weather-Resistance
UV Resistant Epoxy
Water Clear Type
●
●
●
●
●
0.76+0.1
1.5+0.1
●
●
Decoration and entertainment lighting
Architectural lighting
Other Lighting
5.08+0.2
5.08+0.3
●
2
(Ta=25℃)
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
■
Directivity
2
3
■Absolute
Maximum Rating
Item
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
Value
50
120
5
130
-30 ~ +85
-40 ~ +100
260
℃
/5sec
Unit
mA
mA
V
mW
0
0
℃
℃
-
*Pulse width Max.10ms Duty ratio max 1/10
■Electrical
-Optical Characteristics
Item
DC Forward Voltage
DC Reverse Current
Domi. Wavelength*
Luminous Intensity*
50% Power Angle
(Ta=25℃)
Min.
1.8
-
620
750
-
■
Maximum Forward Current
Unit
70
If( Forward Current-mA)
Maximun Permissible Forward Current Tj=115°C
Symbol
V
F
I
R
λ
D
Iv
2θ
1/2
Condition
I
F
=50mA
V
R
=5V
I
F
=50mA
I
F
=50mA
I
F
=50mA
Typ.
2.1
-
625
1000
180
Max.
2.6
10
630
-
-
V
µA
nm
mcd
deg
60
50
40
30
20
10
0
0
Rth(J-a)=400°C/W
Rth(J-a)=500°C/W
Rth(J-a)=600°C/W
*
1
Tolerance of dominant wavelength is +1nm
*
2
Tolerance of luminous intensity is +15%
10
20
30 40
50 60 70
80 90
Ta(Ambient Temperature -°C)
LED & Application Technologies
http://www.optosupply.com
VER A.0
5.0+0.2
Signage and channel letter
5.0
Automotive tail, stop, turn signal lamps and interior lighting
2.5
■Applications
